298 x 748 x 140 mm
ca. 250 paper towels / 7 l

• Combination consisting of a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Can be installed flush with wall or tiles.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 250 standard paper towels in zigzag fold. Paper size (folded): 240-250 mm x 100-115 mm.
• Waste bin equipped with removable mesh basket. Capacity approx. 7 l.
• Accessible through lockable, continuous, double-skin door.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts and front panels can be replaced as modules.
• Installation dimensions: 300 x 750 x 140 mm
• Mounting: With four screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material and one pack of paper towels.

• Weight (in kg): 11,7

Ø 45 x 63 mm
projection 90 mm

• Tabletop soap dispenser in chrome-plated brass.
• Solid body in brass; visible surfaces high-gloss chrome-plated.
• Design height: 64 mm
  Outlet height: 28 mm
  Projection: 62 mm
• Non-drip soap pump with 500 ml soap container in plastics and pressure valve in brass.
• Also available with 250 ml or 1000 ml containers in plastics.
• 500 ml container in stainless steel as an option for a surcharge.
• Designed for standard liquid soaps.
• Refillable from above by unscrewing the top part.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 22-26 mm,
  surface thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material.

• Weight (in kg): 0,6

Ukse lukukate (väline) D Line FAT AISI 316 Ø70mm roostevaba teras messing

Ø70 mm

Height: * mm

Center - center distance (between screw fixings): 30 mm

Together with British designer Tom Dixon we’ve created FAT, a new line of hardware pieces.

Our Ø70mm Fat external escutcheon f/PZ cylinder hole for the outside of an exterior door (ie. a front door), is enduringly crafted in the highly resilient AISI 316 stainless steel preferred by d line and enhanced by a 20-year product guarantee.

The Fat collection comprises a lever handle, key escutcheon and thumb turn, as well as a door knocker, pull handle, flush pull and door stop. Like the rest of the d line portfolio, each piece is minimalist enough to be timeless in its design, its beauty coming from its rounded profile and inflated silhouette, rather than from superfluous details.

Tom Dixon uses the word ‘fat’ to imply generosity and softness of form. The result lacks any trace of sharpness or angularity and is a collection of pumped-up pieces that are simply ‘fatter’ than the norm.

The collection is available in charcoal, electric blue, polished brass and our signature satin stainless steel.

To achieve the collection’s aesthetic, Tom Dixon has magnified the silhouette of each piece’s ‘normal’ aesthetic. That’s why the diameter of our Fat lever roses and escutcheons are Ø70mm. This means, that our Fat lever handle, escutcheons and thumb turns will match lock cases where the backset minus the rebate is a minimum of 40mm. The center distance between the lever handle and escutcheon/thumb turn should also be a minimum of 71mm. For further information, please contact us.

> Working pressure: 1 to 5 bar

> Flow: 1.9 l/min with flow regulator Anti water-hammer system

> Flow time: 7 seconds - lever upwards 11 seconds - lever downwards

> Hydraulic supply: G 1/2'' x 40

> Thermal resistance: This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme

> Safety: With S® antiblocking system to prevent blocking in continuous flow

> Convenience: Soft-touch Two-coloured ergonomic lever, in glass fiber reinforced polymer

> Delivered with: 1 Filter gasket 1 base gasket 1 fixture nut + 1 stainless steel washer 1 Nut for 12x14 tube 1 rubber flat gasket 1 coloured sticker

> Standards / Approvals: Chrome-plated brass body compliant with standards NF EN1982 / NF EN12164 / NF EN12165 Nickel-Chrome surface treatment compliant with NF EN12540 Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227
