> Working pressure :

1 to 5 bar

> Flow :

5 l/min at 3 bar with integrated flow regulator Anti-water-hammering design

> Flow time :

Adjustable by washer 30 second (-10/+5seconds) timer

> Hydraulic supply :

Inlet M G 1/2" (15x21) - Cold or premixed water

> Thermal resistance :

Resistant to a temperature of 75°C for 30-minute-thermal-shocks

> Security :

Patented anti-blocking "S" system to avoid the water to flow continuously Non-removable, wear-proof red marker

> Delivered with :

2 washers for flow time adjustment 1 Flat gasket
1 Nut 1/2’’ (15x21)
1 patte à vis

1 Rose

> Standards & approvals :

Brass body in accordance with EN 1982, EN 12164, EN 12165
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
