BASIN TAP WA 210-1
Ø 45 x 283 x 185 mm
low pressure
- Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
- Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
- Solid stainless steel body; visible surfaces satin finished.
Further available surfaces: see below.
- High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
- Neoperl® air bubble spray M21 x 1 mm.
- Design height: 283 mm
Outlet height: 199 mm
Projection: 98 mm
Length of lever: 140 mm
- Wear parts can be replaced as modules.
- Installation dimensions: Ø 33-40 mm, surface thickness max. 40 mm
- Mounting: With one counternut.
- Delivery includes fixing material and three flexiblen, stainless steel covered connecting tubes.
AVAILABLE SURFACES | ORDER NUMBERS |
satin finished (standard) |
925277 |
highly polished |
932277 |
Suggested text for specifications:
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: low pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 283 x 185 mm
Outlet height 199 mm
Projection 98 mm
Length of lever 140 mm
Article No. WA210-1
Tootekood: WAG-WA210-1
, Tarneaeg: 14-21 päeva
