400 x 1350 x 400 mm
950 ml tank

• Hygiene station consisting of a sensor-disinfectant dispenser and a floor-stand in robust, germ-reducing and easy-care stainless steel.
• Visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Sensor-disinfectant dispenser in stainless steel (AISI316L); all corners fully welded.
  • With EWAR® eModule touch-free operated disinfectant pump with 950 ml tank.
  • Designed for standard disinfectants.
  • Inspection slot to indicate fill level.
  • Accessible for refilling through lockable, hinged housing.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  • Wear parts can be replaced as modules.
  • Delivery includes batteries.
• Floor-stand in stainless steel (AISI304)
  • Base plate with rubber feet.
  • Intended for free floor installation.

• Weight (in kg): 10,3

Ø 30 x 86 mm
projection 76 mm

• Tabletop disinfectant dispenser in chrome-plated brass.
• Solid body in brass; visible surfaces high-gloss chrome-plated.
• Design height:86 mm
  Outlet height: 68 mm
  Projection: 76 mm
• Non-drip disinfectant pump with 500 ml disinfectant bottle in plastics and pressure valve in brass.
• Also available with 250 ml or 1000 ml containers in plastics.
• 500 ml container in stainless steel as an option for a surcharge.
• Designed for standard disinfectants.
• Refillable from above by unscrewing the top part.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 22-26 mm,
  surface thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material.

• Weight (in kg): 0,7

80 x 248 x 120
700 ml tank

• Disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• All-stainless steel housing with rounded vertical corners. Visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• One-hand operated disinfectant pump with 700 ml tank.
• Tank with large, lockable refill opening.
• Designed for standard disinfectants for hands.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, hinged housing.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 1,2
