Delabie Paneel seinale, valamule CANAL 1800mm, R/V teras

2-ne Valamu jalaga 1200x700, kõrgus 850mm , R/V teras

Нержавеющая большегрузная двойная мойка на ножках, 1200 x 700 x 850 мм

Характеристики

stainless steel bulk double-sink with a sheating
without a tap hole (could be made to order)
possibility of fine plane regulation by the regulation screws on the supporting legs
possibility to order inner sinks in dimensions: 400 x 300 x 200 mm/ 400 x 400 x 250 mm/ 400 x 400 x 200 mm
available also in the length 1400 mm
material CrNi 18/10 (AISI-304)
brushed finish
different dimensions could be made to order

Арт. №	93160
Название	SLUN 16

Tootekood: SA-SLUN16 , Tarneaeg: 3-5 nädalad

2745,00 €

Antivandaalne WC pott R/V taras

	AUZ 08 stainless-steel standing closet, with hardened seat, back drain

AUZ 08 is a stainless-steel WC in matt design. To increase the user comfort, it is provided with a grey seat with a lid made of hardened plastic (newly also with a seat in black design AUZ 08.CS). AUZ 08 is designed to stand on the floor at the wall; it is suitable for places where the common closet cannot be attached to the wall, because of a thin bearing particle, for example. The standard version of AUZ 08 has a back drain (the version with the bottom drain AUZ 02). It is suitable to supplement the WC with the automatic pressure water flushing device AUZ 3, automatic flushing device with the piezo button AUZ 3.P (or the vandal-resistant flushing device BSAZ 01) or any flushing device with a cistern.

Thanks to its resistance to damage, the closet is primarily intended for social facilities with demanding operation, such as highway lay-byes, alehouses, etc., where easy maintenance of sanitary conditions is required. WC is also manufactured in the design for the disabled under the designation AUZ 08 INV.

Further closet versions can be found in the section Stainless-steel closets or Stainless-steel safety closets.

Basic technical information
Water inlet:	d= 34-50 mm
Min. water flow:	70 l/min
Outlet:	d= 90 mm
Weight:	23 kg

Requirements for setting up the construction
Set-up outlet d = 110 mm including rubber sleeve for pipe d = 90 mm. Set-up water inlet d= 34-50 mm according to chosen sealing.

Complete delivery
Stainless steel closet Plastic seat Anchoring material

Made to order
AUZ 3 - automatic pressure flushing system AUZ 3.P - automatic pressure flushing system with piezo control BSAZ 01 - vandal resistant pressure flushing system

Tootekood: AZP-AUZ 08 , Tarneaeg: 3-4 nädalad

2452,00 €

Automatne kummikute pesur düüsiga, 12V, 50Hz

automatic washing system for wellingtons with jets - 12V, 50Hz

AMO 01 is a stainless steel automatic washing system for wellingtons with sensor-controlled water nozzles. When stepping into the washing chamber of the system (scanning zone) water starts to flow from the nozzles automatically and wellingtons are cleaned of dirt. Water stops flowing with a certain time delay after the foot has been removed from the scanning zone.
AMO 01 is designed for a single pipe inlet of pre-mixed water from the circulation or water pre-mixed by means of a thermostatic valve.
The AMO 01 automatic washing system is intended mainly for operations with slight shoe contamination where quick washing at maximum water savings is guaranteed.

Package contents

body of the washing machine
photocell head
nozzles – 8 pcs
electromagnetic valves 2 pcs
corner valves with filter
connecting hoses

Radius of sensor	0 – 0,4 m
Water inlet	G 1/2“
Water pressure	0,3 – 1,0 MPa
Outlet	d = 32 mm
Inner dimensions of the trough	250 x 400 x 280 mm
Electricity protection	IP 55
Power supply	12 V, 50 Hz
Power requirement	10 VA
Source of power supply	ZAC 1/20 (max. 2 x AMO 01)
	ZAC 1/50 (max. 5 x AMO 01)
Weight	18 kg

Set up water inlet as per picture
Set up outlet d = 32 mm
Set up cable for power supply – 12 V, 50 Hz from source of power supply ZAC

Tootekood: AZP-AMO 01 , Tarneaeg: 3-5 nädalat

2405,00 €

Joogifontään seinale sensoriga R/V teras AISI316(basseinid) 6V(4x1.5V)

AFO 01.Yst. steel sensor controlled drinking fountain

AFO 01.Y is st. stainless wall hung drinking fountain controlled by sensor. Water runs after disrupting the scanning zone.

Fountain is made by welding all components together.

Fountain is suppplied with safety power 12 V, 50 Hz from power supply ZAC (AFO 01.Y) or with 4x AA battery (AFO 01.YB).

Material is standardly st. steel AISI 304 or can be AISI 316 (AFO 01.Y.CL or AFO 01.YB.CL).

St. steel driking fountain AFO 01.Y is based on favourite model AFO 01 with manual control.

The sensor, located on the right side of the fountain, is reacting on the approach of the user. Water starts to run from the nozzle, located in the middle of the fountain bowl, and runs over the time when the user´s head is in the scanning zone (max. 30 sec.) + preset time (max. 4 sec.) to clean the nozzle.

Package contents

st. steel drinking fountain
nozzle
sensor and electronic
electromagnetic valve
connecting flexible hose
corner valve with filters
siphon
mounting material

water inlet	G 1/2"
water pressure	1 - 10 Bar (AFO 01.Y; AFO 01.Y.CL)
	2 - 8 Bar (AFO 01.YB; AFO 01.YB.CL)
outlet	d = 40 mm
bowl inner dimension	d = 245 mm
weigth	4 kg
suppply	12 V, 50 Hz (AFO 01.Y; AFO 01.Y.CL)
	6 V - 4 x AA battery (AFO 01.YB; AFO 01.YB.CL)
power supply	ZAC 1/20 (max. 3 x AFO 01.Y ; AFO 01.Y.CL)

Tootekood: AZP-AFO01.YB.CL , Tarneaeg: 3-4 nädala

1281,00 €

Joogifontään veejahutussüsteemiga, pudeli taitmisega põrand/sein piezo nupp, R/V teras AISI304 230V/50Hz

AFO 01.SCL

drinking fountain with cooling and spout for filling bottles designed to stand and to be attached to wall

AFO 01.SCL is a drinking fountain with cooling and spout for filling bottles designed to stand and to be attached to wall. User can select between uncooled water and water running through a flow cooler. Uncooled water is used for bottle filling as a standard – can be changed. Start/stop control by piezo-buttons – resistant solution. Facility keeper can set a time period after which the water flow automatically stops.

The product contains a flow cooler. It is not a design with cooled tank only where – after the pre-cooled amount of water is pumped out – the user has to wait for the next charge to be cooled.

Water supply is provided by a flexible hose, trap comprises an elastic flexible couple. Flexible design of water supply and outflow allows variable and easy connection of the drinking fountain as well as its dismounting.

Automatic drinking fountain (with a sensor) can be supplied per order.

AFO 01.SCL is manufactured from the stainless steel AISI 304. Other materials (e.g. AISI 316) possible on order. For cleaning we recomnned WÜRTH detergents – material preservation (no. 0893 121 K) and material cleaning (no. 893 121 1).

Package contents

Stainless housing with cone
Electronics and control piezo-buttons
Water supply and electromagnetic valves
Flow cooler
Flexible hose outflow
Fixing and connecting material

dimensions	330 x 900 x 365 mm
water outlet	d = 40 mm
water inlet	G 1/2"
water pressure	0,2 – 0,6 MPa, recommended 0,3 MPa
power supply	230 V, 50 Hz
power input	830 W
weight	25 kg

Set up water outlet d = 40 mm
Set up water inlet G 1/2"
Electric socket 230 V, or set up electric cable CYKY 3C x 1,5

Tootekood: AZP-AFO01.SCL , Tarneaeg: 3-4 недели

5765,00 €
