Dushi kraanile Presto 500S vajutusnupp kroomitud
Kaubamärk:
Ühik: tk
Tarneaeg: 7-14 päeva
Müüja: PEGU OÜ
Rem komplekt Sisule Presto 500S/500S PAP/500S B (2 tk)
X.Eclair TC Presto ref.13120, läbi seina paigaldus,nuputa auguta
Tagaseina auk on kini.
Recommended operating pressure: 1 to 5 bar
Flush volume: 6 to 9 l, adjustable by operating the shut-off valve Anti-water hammer device
Flow time: 7 to 9 seconds
Hydraulic supply: In line, double male G 1"1/4 (33x42) Outlet connection on flush tube Ø 32 mm
Material and colour of finish: Brass body, raw
Delivered with: 1 Flash box with syphonic action 1 Assembly instructions
Standards / Approvals : Brass body in compliance with NF EN1982 / NF EN12164 / NF EN12165 standards
Delabie profiköögi segistile voolik 950 mm must
Food-grade flexible hose for catering
Ref. 433095CH
PVC sheath on stress area.
Anti-torsion rotating nut.
Flexible hose will withstand temperatures up to 70°C and 5 bar maximum pressure.
Spare part for repairing pre-rinse set components.
TECHNICAL CHARACTERISTICS
Food-grade flexible hose for catering
Ref. 433095CH| Length | L. 0.95m |
| Finish | Hytrel |
Pissuaari ventiil antivandaalne Presto P12, 6 sek 1/2"
> Working pressure :
1 to 5 bar
> Flow :
9 l/min at 1 bar - 4-positions flow adjustment device Anti-water-hammering design
> Flow time :
6 seconds (± 2 sec.)
> Hydraulic supply :
In-line water inlet
M G 1/2" Inlet and outlet
> Delivered with :
1 Flat gasket and 1 Union nut 1 Nut for 12x14 tube
> Standards & approvals :
Brass body in accordance with EN 1982, EN 12164, EN 12165 200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
Presto sirge STOP kraan P41000 WC ECLAIR XL mehhanismile 1 1/4" ref.13060, 13070
