Dušiiste , seina pealne
Kaubamärk:
![Idral-PEGU](https://www.pegu.ee/media/gavial/.image/brand-thumb/general/Idral/IDRAL_uff.jpg)
Ühik: tk
Tarneaeg: 3 nädalat
Kohustuslik märge projekti spetsifikatsioonis: PEGU OÜ
Kuni 100kg
Failid
Components and Materials · Chromed brass bar Ø 25 mm, 1 mm thick, with a protection thickness of 9,4 µm nickel + 0,40 µm chrome. · Soap basket with chromed brass rods Ø 8 and 3 mm, with a protection thickness of 21 µm nickel + 0,20 µm chrome. · Chromed brass snap flange cover, 2 units with a protection thickness of 21 µm nickel + 0,20 µm chrome. · Press-formed mounting flanges, 2 units. Each flange incorporates 3 screws holes of Ø 5 mm for mounting on the wall
Nova2 Care
General description
-
Wall-floor grab bar, with three support points, made of a diameter of 32 mm AISI 304 stainless steel tube, bent in an "L" shape at 90o and with a 32mm diameter lateral arm, welded on the lower part of the grab bar and also bent at 90°.
-
With snap flange covers that conceal the installation screws, improving the aesthetics of the bars once installed on the wall.
-
These grab bars offer a great safety and comfort to the user, helping to make the bathroom much safer for the elderly or those with reduced
mobility. Models suitable for public use.
-
Well suited for keeping bathrooms and public enclosures barrier-free.
-
Highest durability and great resistance to rusting.
-
Optionally, these grab bars can be electrically isolated, installing the electrical isolation kit code KA0020.
-
Supplied with plugs and screws to fix the bar to a brick wall.
Components and materials
-
BSD020C: right hand grab bar made of AISI 304 stainless steel tube, bright finish.
-
BSI020C: left hand grab bar made of AISI 304 stainless steel tube, bright finish.
-
BSD020CS: right hand grab bar made of AISI 304 stainless steel tube, satin finish.
-
BSI020CS: left hand grab bar made of AISI 304 stainless steel tube, satin finish.
-
TUBING: made of a 32 mm diameter tube, seamless construction. The bending process guarantees the uniformity of the diameter along the bends.
-
CONCEALED MOUNTING FLANGE: three units made of AISI 304 stainless steel, 3 mm thick. Incorporates two Ø 6.5 mm screw holes for wall mounting.
-
SNAP FLANGE COVER: three units made of AISI 304 stainless steel, 0.8 mm thick and Ø 82 mm. Each cover snaps over mounting flange to conceal mounting screws.
-
General description
L454 x L869 mm
-
Grab bar, 90o angle to the right (BAD090C & BAD090CS) or to the left (BAI090C & BAI090CS) with snap flange cover, made of stainless steel AISI 304, for showers, baths and changing rooms.
-
These grab bars are very useful and highly recommended to achieve barrier-free accessibility both residential and public spaces.
-
Concealed screw mounting flanges.
-
Highest durability and rusting resistance.
-
Mounting hardware for brick wall is included for easy installation.
Components and materials
-
BAD090C & BAI090C: AISI 304 stainless steel, bright finish.
-
BAD090CS & BAI090CS: AISI 304 stainless steel, satin finish.
-
TUBING: made of 32 mm diameter tube, seamless construction. The bending process guarantees the uniformity of the diameter along
the bends.
-
CONCEALED MOUNTING FLANGE: three units made of AISI 304 stainless steel, 3 mm thick. Incorporates two Ø 6.5 mm screws holes
for wall mounting.
-
SNAP FLANGE COVER: three units made of stainless steel AISI 304, 1.5 mm thick and Ø 82 mm. Each cover snaps over mounting
flange to conceal mounting screws.
Be-Line drop-down support rail with leg, L. 850mm, white
Ref. 511963W
Be-Line drop-down support rail for people with reduced mobility.
In the lowered position use as a grab bar, as a support for standingand for assisting movement, for WCs or showers.
Allows side access in the raised position.
Removable: easy to remove with anti-theft locking system. Reduces the number of barsin a facility, allowing installation only when required.
Example: hotels or hospitals providing short-term accommodation for people with reduced mobility.
Retained in upright position. Slowed down descent.
Aluminium tube.
Rounded profile Ø 42mm with ergonomic flat front face that prevents rotation for an optimal grip.
Matte white powder-coated aluminium finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
Concealed fixings secured to wall by a 304 stainless steel plate, 5mm thick.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
Leg provides additional reinforcement when wall fixings are not enough.
Dimensions: 850 x 825 x 120mm.
Leg height can be adjusted from 760 - 780mm.
Tested to over 200kg. Maximum recommended user weight: 135kg.
TECHNICAL FEATURES
Be-Line drop-down support rail with leg, L. 850mm, white
Ref. 511963W
Height | 210mm |
---|---|
Length | 850mm |
Width | 120mm |
Finish | Powder-coated matte white aluminium |
