Wall-hung individual rimless urinal. Compatible with all standard frame systems on the market. Bacteriostatic 304 stainless steel. Polished satin finish. Stainless steel thickness: 1.2mm. Rear (recessed) water inlet. Recessed waste outlet. Concealed trap. Quick and easy to install from the front thanks to a stainless steel mounting frame. Supplied with 1½" P trap, fixing elements and theft prevention TORX security screws. CE marked. Complies with European standard EN 13407 for 2L flush. Weight: 7.5kg.
KOMPACT TC washbasin and wall-hung WC combination Ref. 166400
Combination unit: washbasin and suspended WC pan on left sidewith recessed toilet roll holder. Service duct installation (through-the-wall). Bacteriostatic 304 stainless steel. Polished satin finish. Stainless steel unit thickness: 2mm. Rounded corners and edges for improved safety. Smooth surface for easy cleaning. Suitable for prisons, police stations, etc. WC pan is completely welded to washbasin, no screws: makes cleaning easier and prevents concealment of objects. Left hand WC pan Washbasin equipped with time flow tap: stainless steel tamperproofpush-button and anti-blocking system, 7 second time flow, M1/2". WC equipped with time flow flush valve, 7 second time flow, M3/4". Water inlet: washbasin M1/2", WC M3/4". Recessed horizontal water outlet: Ø 100mm. 200mm threaded rod can be cut to size (other lengths available on demand). Weight: 30kg. [Formerly ref: 0616130004]
Technical features
KOMPACT TC washbasin and wall-hung WC combination Ref. 166400
Complete pre-rinse set with bib tap. Single hole deck-mounted mixer with slimline control lever. Supplied with F3/8" flexible hoses and non-return valves. Bib tap with swivelling, tubular spout L. 200mm. - 16 lpm full flow rate achieved within the first 90°. - Valve head with reinforced mechanism and ergonomic control. Black, scale-resistant M1/2" hand spray with adjustable jet and 9 lpm flow rate at the outlet. Reinforced, food-grade black flexible hose L. 0.95m. 3/4" brass column. Adjustable wall bracket. Stainless steel spring guide.
