298 x 1198 x 140 mm
ca. 750 paper towels / 13 l

• Combination consisting of a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Can be installed flush with wall or tiles.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 750 standard paper towels in zigzag fold. Paper size (folded): 240-250 mm x 100-115 mm.
• Waste bin equipped with removable mesh basket. Capacity approx. 13 l.
• Accessible through lockable, continuous, double-skin door.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts and front panels can be replaced as modules.
• Installation dimensions: 300 x 1200 x 140 mm
• Mounting: With four screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material and one pack of paper towels.

• Weight (in kg): 18,2

Double, CC600mm. Available in brushed and polished. Nova. N1105

> Working pressure : 1 to 5 bar

> Flow : 6 l/min at 3 bar - 4-position flow adjustment device Anti-water-hammering design

> Flow time : 3 to 5 seconds

> Operation : Foot-operated activation through pedal

> Hydraulic supply : Inlet M G 1/2"(15x21) - Cold or premixed water

> Material and colour finish : Brass body and components with molded chrome treatment Technical polymer

> Thermal resistance : Resistant to a temperature of 75°C for 30-minute-thermal-shocks

> Delivered with : 1 Gasket nut 1 Coupling nut 1 Nut for 12x14mm tube Instruction manual

> Standards & approvals : Acoustic class II Brass body in accordance with EN 1982, EN 12164, EN 12165 Molded chrome-plated body in accordance with EN 12540 200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
