298 x 298 x 121 mm
950 ml soap bottle / 950 ml tank disinfectant / 950 ml bottle lotion

• Sensor combination consisting of a sensor liquid soap-, disinfectant- and lotion dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Sensor soap or lotion dispenser with EWAR® eModuletouch-free operated and non-drip soap and lotion pump.
  Designed for standard 950 ml disposable bottles of liquid soap or lotion. Also refillable with large container using the plug-in tank as an option
• Sensor disinfectant dispenser with EWAR® eModule touch-free operated disinfectant pump with 950 ml tank arranged in the middle. Designed for standard disinfectants.
• Note: Not approved for medical areas.
• Inspection slots to indicate fill level.
• Accessible for refilling through lockable, hinged housing.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  Power supply available as an option.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material, batteries and first fill with soap and lotion.

• Weight (in kg): 6,4

12 bottles x 950 ml
370 x 240 x 235 mm

Biologically degradable
Packacking unit: 12 bottles x 950 ml; 12,4 kg

SUITABLE FOR:

• L 109
• L 109E
• WP 102
• WP 102E
• WP 173
• WP 173E
• WP 174-2
• WP 174E-2
• WP 208
• WP 208E
• WP 500
• WP 500E
• WP 510
• WP 510E
• WP 575
• WP 575E
• WP 600
• WP 600E
• WP 650
• WP 650E
• WP 5410
• WP 5415
• WP 5420
• WP 5425
• WP 5710
• WP 5715
• WP 5720
• WP 5725

448 x 1348 x 220 mm
1 paper roll / 48 l

• Combination consisting of a sensor paper roll dispenser (battery-powered) and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Paper roll dispenser with touch-free operated, capacitive sensor technology, sensor distance approx. 3.5 cm. Paper length and idle time adjustable.
  Battery-powered with four standard 1.5 V Mono/LR20/12 A batteries.
• Designed for one paper roll with dimensions:
  Width 215 mm, outer diameter max. 180 mm,
  inner diameter 50 mm.
• Inspection slot to indicate fill level, residual roll function allows a reserve roll to be inserted before residual roll is completely used up.
• Waste bin equipped with removable mesh basket. Capacity approx. 48 l.
• Accessible through lockable doors.
• Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
• Wear parts and front panels can be replaced as modules.
• Installation dimensions: 450 x 1350 x 210 mm (when fully fitted).
• Mounting: With six screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material and first fill with one paper roll.

• Weight (in kg): 25,8
