Köögisegisti, sisaldab X-Change TM ühendust

AZP Brno adapter 1-3 punkte

	ZAC 1/20, ZAC 1/50, ZAC 1/36L power supply

ZAC is a safe source of voltage supply intended to power automatic sanitary equipment made by AZP Brno, Ltd.

The source of power supply consists of a safety transformer produced in accordance with ČSN IEC 742+A1 standards. All kinds of sensors can be connected to these sources in random combinations, as can other devices with a supply voltage of 12 V, 50 Hz (total power requirement either 20 VA, 50 VA or 36 VA).

ZAC 1/20 and ZAC 1/50 are independent sources, 1/36L ZAC is the source for the location on the DIN-rail (4 modules).

Version types
ZAC 1/20 - source of power supply with output 20 VA
ZAC 1/50 - source of power supply with output 50 VA
ZAC 1/36L - source of power supply with output 36 VA

Source of power supply can be placed at a maximum distance of 30 m from the connected appliance.

Basic technical information
Input voltage:	230 V, 50 Hz
Output voltage:	12 V, 50 Hz
Power requirement:	20 VA (ZAC 1/20)
	50 VA (ZAC 1/50)
	36 VA (ZAC 1/36L)
Electricity protection:	IP 55 (ZAC 1/20, ZAC 1/50)
	IP 20 (ZAC 1/36L)
Weight:	0,8 kg (ZAC 1/20, ZAC 1/36L)
	1,2 kg (ZAC 1/50)

Requirements for setting up the construction

ZAC 1/20, ZAC 1/50

Set-up supply of electricity 230 V,50 Hz – cable CYKY 3Cx1,5
Set-up niche for flush mounting – size as per installed source
Distribution to each device is carried out by cable CYKY 2Ax1,5

ZAC 1/36 L

It is installed on the DIN-rail - width of 4 modules

Figure
ZAC 1/20

ZAC 1/50

Product title

ZAC 1/20 -

power supply for up to 3 devices - 230V, 50Hz

ZAC 1/50 -

power supply for up to 8 devices - 230V, 50Hz

ZAC 1/36L -

power supply for up to 6 devices - 230V, 50Hz

Tootekood: AZP-ZAC 1-20 , Tarneaeg: 3-4 nädalad

105,00 €

Intra ICON valamu IC1 harjatud, alt paigaldamiseks

General

Size (mm):	525 x 334 x 97
Large bowl (mm):	500 x 310 x 83
Designer:	Halvor Thorsen

Description

Icon hand wash basin IC1-22 in stainless steel 18/10, is designed for under mounting.The hand wash basin is pressed in one piece and has laser-cut integrated outlet holes that are concealed by a removable outlet cover.The basin is supplied with waste. Without overflow.

Brushed finish.

Tootekood: I-IC1 32N , Tarneaeg: 14-21 päeva

439,00 €

Intra GUB3 R/V teras valamu, ämberresti ja pritsmisplekiga, äravool 100mm

Valamu R/V terasest

Garaazi/koristusruumi jaoks

Tootekood: I-GUB3 , Tarneaeg: 14 -21 päeva

355,00 €

Pissuaari mehhanism infra-red paigalduse karbiga, 24 V DC

SLP 02K

Urinal infra-red flushing unit with a mounting box, 24 V DC

Characteristics

system reacts to the user attendance in front of the urinal at a maximum distance of 0,7 m, minimum stay time in active range is 7,5 s
water flows after the user leaves active range
adjustable flushing time 0,5 - 15,5 s
parameters adjustment by remote control SLD 03
automatic hygiene flushing after 24 hours non-use
possibility to regulate a water flow by the ball valve

Order number	01022
Code	SLP 02K

Supply specification

SLP 02K - Supply No. 01022 - stainless steel cover with electronics, plastic mounting box with brass screw coupling, electromagnetic valve and ball valve

Technical information

Stainless steel cover dimension: 170 x 170 x 10 mm
Mounting box dimension:140 x 140 x 75 mm
Operating voltage: 24 V DC
Active range: 0,6 - 0,75 m
Recommended flow pressure: 0,1 - 0,6 MPa
Rate of flow: 18 l/min (inf. data)
Water inlet: male thread G 3/4“
Water outlet: male thread G 3/4“

Tootekood: SA-SLP02K , Tarneaeg: 14-21 päeva

355,00 €

COMPACTO WC+valamu sümmetriline põranda, antivandaalne R/V teras AISI304

R/V teras WC pott ja valamu

AISI304 paksus 1,5 mm

Kinnitus poltidega läbi seina

Loputus ühendus 1"

WC äravool 100mm

Valamu ärravool 32mm

NB! Vee mehhanismid on vaja tellida eraldi

Tootekood: PCOMP-003TS , Tarneaeg: 6-7 nädalad

2928,00 €
