AZP Brno adapter 1-3 punkte

	ZAC 1/20, ZAC 1/50, ZAC 1/36L power supply

ZAC is a safe source of voltage supply intended to power automatic sanitary equipment made by AZP Brno, Ltd.

The source of power supply consists of a safety transformer produced in accordance with ČSN IEC 742+A1 standards. All kinds of sensors can be connected to these sources in random combinations, as can other devices with a supply voltage of 12 V, 50 Hz (total power requirement either 20 VA, 50 VA or 36 VA).

ZAC 1/20 and ZAC 1/50 are independent sources, 1/36L ZAC is the source for the location on the DIN-rail (4 modules).

Version types
ZAC 1/20 - source of power supply with output 20 VA
ZAC 1/50 - source of power supply with output 50 VA
ZAC 1/36L - source of power supply with output 36 VA

Source of power supply can be placed at a maximum distance of 30 m from the connected appliance.

Basic technical information
Input voltage:	230 V, 50 Hz
Output voltage:	12 V, 50 Hz
Power requirement:	20 VA (ZAC 1/20)
	50 VA (ZAC 1/50)
	36 VA (ZAC 1/36L)
Electricity protection:	IP 55 (ZAC 1/20, ZAC 1/50)
	IP 20 (ZAC 1/36L)
Weight:	0,8 kg (ZAC 1/20, ZAC 1/36L)
	1,2 kg (ZAC 1/50)

Requirements for setting up the construction

ZAC 1/20, ZAC 1/50

Set-up supply of electricity 230 V,50 Hz – cable CYKY 3Cx1,5
Set-up niche for flush mounting – size as per installed source
Distribution to each device is carried out by cable CYKY 2Ax1,5

ZAC 1/36 L

It is installed on the DIN-rail - width of 4 modules

Figure
ZAC 1/20

ZAC 1/50

Product title

ZAC 1/20 -

power supply for up to 3 devices - 230V, 50Hz

ZAC 1/50 -

power supply for up to 8 devices - 230V, 50Hz

ZAC 1/36L -

power supply for up to 6 devices - 230V, 50Hz

Tootekood: AZP-ZAC 1-20 , Tarneaeg: 3-4 nädalad

105,00 €

Antivandaalne WC pott R/V taras

	AUZ 08 stainless-steel standing closet, with hardened seat, back drain

AUZ 08 is a stainless-steel WC in matt design. To increase the user comfort, it is provided with a grey seat with a lid made of hardened plastic (newly also with a seat in black design AUZ 08.CS). AUZ 08 is designed to stand on the floor at the wall; it is suitable for places where the common closet cannot be attached to the wall, because of a thin bearing particle, for example. The standard version of AUZ 08 has a back drain (the version with the bottom drain AUZ 02). It is suitable to supplement the WC with the automatic pressure water flushing device AUZ 3, automatic flushing device with the piezo button AUZ 3.P (or the vandal-resistant flushing device BSAZ 01) or any flushing device with a cistern.

Thanks to its resistance to damage, the closet is primarily intended for social facilities with demanding operation, such as highway lay-byes, alehouses, etc., where easy maintenance of sanitary conditions is required. WC is also manufactured in the design for the disabled under the designation AUZ 08 INV.

Further closet versions can be found in the section Stainless-steel closets or Stainless-steel safety closets.

Basic technical information
Water inlet:	d= 34-50 mm
Min. water flow:	70 l/min
Outlet:	d= 90 mm
Weight:	23 kg

Requirements for setting up the construction
Set-up outlet d = 110 mm including rubber sleeve for pipe d = 90 mm. Set-up water inlet d= 34-50 mm according to chosen sealing.

Complete delivery
Stainless steel closet Plastic seat Anchoring material

Made to order
AUZ 3 - automatic pressure flushing system AUZ 3.P - automatic pressure flushing system with piezo control BSAZ 01 - vandal resistant pressure flushing system

Tootekood: AZP-AUZ 08 , Tarneaeg: 3-4 nädalad

2452,00 €

Intra U1 R/V teras L375mm kompaktne koristaja valamu, pritsmisplekiga

Valamu R/V terasest

Garaazi/koristusruumi jaoks

Tootekood: I-U1STD , Tarneaeg: 7-14 päeva

329,00 €

Pissuaari mehhanism infra-red paigalduse karbiga, 24 V DC

SLP 02K

Urinal infra-red flushing unit with a mounting box, 24 V DC

Characteristics

system reacts to the user attendance in front of the urinal at a maximum distance of 0,7 m, minimum stay time in active range is 7,5 s
water flows after the user leaves active range
adjustable flushing time 0,5 - 15,5 s
parameters adjustment by remote control SLD 03
automatic hygiene flushing after 24 hours non-use
possibility to regulate a water flow by the ball valve

Order number	01022
Code	SLP 02K

Supply specification

SLP 02K - Supply No. 01022 - stainless steel cover with electronics, plastic mounting box with brass screw coupling, electromagnetic valve and ball valve

Technical information

Stainless steel cover dimension: 170 x 170 x 10 mm
Mounting box dimension:140 x 140 x 75 mm
Operating voltage: 24 V DC
Active range: 0,6 - 0,75 m
Recommended flow pressure: 0,1 - 0,6 MPa
Rate of flow: 18 l/min (inf. data)
Water inlet: male thread G 3/4“
Water outlet: male thread G 3/4“

Tootekood: SA-SLP02K , Tarneaeg: 14-21 päeva

355,00 €

Joogifontään AFO04 seinale mehaaniline R/V teras AISI316(basseinile)

AFO 04

suspension drinking fountain

AFO 04 is a stainless-steel drinking fountain of a modern design. It is manufactured with a double surface finish: matt bowl (blasted with ballotini) and brushed casing. Thanks to its interesting appearance, it particularly suits public spaces, such as sports facilities, parks, squares, business centres, fitness and wellness centres, but also schools and kindergartens.

Similarly to AFO 01, the drinking fountain is operated with a push valve. Water is flowing while the valve is pushed and for a preset time after its release, in which way the nozzle is rinsed.

The water inlet is through a flexible hose; siphon trap is made of a flexible coupling. The flexible design of the water inlet and outlet enables variable and trouble-free connection of the fountain as well as its simple dismounting.

The AFO 04 drinking fountain is made from stainless steel of the AISI 304 class; the AFO 04.CL drinking fountain is made from steel of the AISI 316 class.

Package contents

stainless steel casing
press valve
corner valve with filter
fixing bar
siphon
connecting hose
anchoring material

Water inlet	G 1/2"
Water pressure	2 - 6 Bar (recommended 3 Bar)
Outlet	d = 40 mm
Inner dimension of the fountain	d = 245 mm
Weight	4 kg

Set-up water inlet - pipe G1/2“.
Set-up drainage d = 40 mm.

Tootekood: AZP-AFO04.CL , Tarneaeg: 3-4 nädalad

1226,00 €
