Ø 30 x 86 mm
projection 76 mm

• Tabletop disinfectant dispenser in chrome-plated brass.
• Solid body in brass; visible surfaces high-gloss chrome-plated.
• Design height:86 mm
  Outlet height: 68 mm
  Projection: 76 mm
• Non-drip disinfectant pump with 500 ml disinfectant bottle in plastics and pressure valve in brass.
• Also available with 250 ml or 1000 ml containers in plastics.
• 500 ml container in stainless steel as an option for a surcharge.
• Designed for standard disinfectants.
• Refillable from above by unscrewing the top part.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 22-26 mm,
  surface thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material.

• Weight (in kg): 0,7

Newicon Brabantia prügikast 12l pedaaliga vaikselt sulguv Platinum

PEDAL BIN NEWICON

Käterätikuivati on valmistatud messingist. (brass)

Полотенцесушители выполнены из латуни

Sobib nii küttevee kui ka tarbevee süsteemi.

Подходят как для отопительной системы, так и для ГВС

Maksimaalne töörõhk on 600 KPa

Максимальное рабочее давление 600 KPa

Maksimaalne temperatuur 85°C

максимальная температура 85°C

Võimalikud viimistlused Chroom +...%

Возможные покрытия Chroom +...%

298 x 1048 x 220 mm
ca. 250 paper towels / 32l

• Combination consisting of a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 250 standard paper towels in zigzag fold.
  Paper size (folded): 240-250 mm x 100-115 mm.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable front flap with fall protection.
• Waste bin equipped with removable mesh basket.
  Capacity approx. 32 l. Accessible through lockable door.
• Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material and one pack of paper towels.

• Weight (in kg): 13,4
