SECURITHERM shower panel
Ref. 792305

298 x 1348 x 120 mm
ca. 250 paper towels / 950 ml soap bottle / 11 l

• Combination consisting of a liquid soap dispenser, a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Liquid soap dispenser with one-hand operated and non-drip soap pump.
• Designed for standard 950 ml disposable bottles of liquid soap or hand lotion.
• Also refillable with large container using the plug-in tank as an option.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 250 standard paper towels in zigzag fold.
  Paper size (folded): 240-250 mm x 100-115 mm.
• Inspection slots to indicate fill level.
• Accessible for refilling through lockable front flap with fall protection.
• Waste bin equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
• Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
• Wear parts and front panels can be replaced as modules.
• Installation dimensions: 300 x 1350 x 110 mm
• Mounting: With eight screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material, first fill with soap and one pack of paper towels.

• Weight (in kg): 15,4

12 bottles x 950 ml
370 x 240 x 235 mm

Biologically degradable
Packacking unit: 12 bottles x 950 ml; 12,4 kg

SUITABLE FOR:

• L 109
• L 109E
• WP 102
• WP 102E
• WP 173
• WP 173E
• WP 174-2
• WP 174E-2
• WP 208
• WP 208E
• WP 500
• WP 500E
• WP 510
• WP 510E
• WP 575
• WP 575E
• WP 600
• WP 600E
• WP 650
• WP 650E
• WP 5410
• WP 5415
• WP 5420
• WP 5425
• WP 5710
• WP 5715
• WP 5720
• WP 5725
