> Working pressure :

1 to 5 bar

> Flow :

4l/min Flow limiter / 5-position flow adjustment device inaccessible to users Anti-water-hammering design
Vandalism proof and anti-clogging spout

> Flow time :

15 seconds ( ± 5 sec.) - 4-position flow adjustment device

> Operation :

Simple push-button action to activate the water flow

> Hydraulic supply :

M G 1/2" (15x21) - Premixed water (Red skirt)

> Thermal resistance :

Resistant to a temperature of 75°C for 30 minute thermal shock

> Delivered with :

1 G 1/2" nut for 12x14 tube with filter gasket 1 Stainless steel plain washer
1 Brass clamping nut
1 Nitrile plain washer

Instruction manual

> Standards & approvals :

Acoustic class I
Brass body in accordance with EN 1982, EN 12164, EN 12165 Chrome-plated surface treatment in accordance with EN 12540 200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
