Seebidosaatori eModule (ilma patareideta, Wagner Ewar)

Infrapunaanduriga moodulit saab kasutada mitmes EWAR® seebidosaatoris ja kombinatsioonides seebidosaatoritega.
Alternatiivselt võib kasutada kaubanduslikult saadaval olevaid 500 ml või 950 ml seebipudeleid või 200 ml mahutit.
Tööpingepinge: 3V (2 LR14 patareid), kuni 3000 aktiveerimist.
Patareipesa asub paremal ja on hõlpsasti ligipääsetav ilma seebimahutit eemaldamata.
3V vooluadapter patareideta kasutamiseks on saadaval lisatarvikuna.
Andurimoodul ja pump on modulaarse kujundusega ning neid saab tööriistadeta vahetada.
Hooldusrežiim: andurimoodul lülitub välja, kui seadme korpus avatakse.
Hoiatusnäidik madala patarei taseme kohta.
Tuvastusvahemik: umbes 5 cm (mõõdetakse automaatselt).
Andur tuvastab valguse muutusi (kaitseb väärkasutuse eest, näiteks anduripinna katmisega).
Kaal: 0,22 kg.

• PP101e-7
• PP102e-1
• PP102e-7
• PP102e-7S
• WP101e
• WP101e-7
• WP102e
• WP102e-1
• WP102e-7
• WP102e-7S
• WP102e-7T
• WP173e
• WP173e-1
• WP173e-7
• WP174e
• WP174e-2
• WP174e-7
• WP208e
• WP208e-7
• WP500e
• WP510e
• WP550e
• WP575e
• WP585e
• WP585e-7
• WP600e
• WP650e

• Infra-red sensor module can be used in several EWAR® soap dispensers and combinations with soap dispensers.
• Alternatively, can be operated with commercially available 500 ml or 950 ml soap bottles or with 200 ml tank.
• Operating voltage 3V, (2 LR14 baby batteries), for up to 3000 actuations.
• Battery compartment on the right is easily accessible without removing the soap tank.
• 3V mains supply for batteryless operation available as an accessory.
• Sensor module and pump in modular design and can be replaced without tools.
• Service mode: sensor module switches off when device housing is opened.
• Warning display for low battery level.
• Detection range approx. 5 cm (is measured automatically).
• Sensor detects light changes (protects against misuse e.g. by masking the sensor surface).
• Weight: 0,22 kg

86 x 298 x 120 mm
850 ml plug-in tank

• Sensor liquid soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• All-stainless steel housing with rounded vertical corners, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• With EWAR® eModule touch-free operated and non-drip soap pump with 850 ml plug-in tank.
• Designed for standard liquid soaps or hand lotions.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, hinged housing.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• eModule battery-powered with two 1.5 V Baby/LR14 batteries. Power supply available as an option.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material and batteries.

• Weight (in kg): 1,7

282 x 392 x 203 mm
ca. 12 l

• Hygiene waste bin with paper sanitary bag dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; visible surfaces satin finished and brushed. Further available surfaces: see below.
• Equipped with removable hygiene bin. Capacity approx. 12 l.
• On the backside integrated paper sanitary bag dispenser. Designed for ca. 100 standard paper sanitary bags.
• Accessible through hinged lid.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 6,4
