Deck-mounted electronic basin mixer:
230/6V plug-in mains supply.
Reduced-stagnation solenoid valve and electronic unit integrated into the body of the mixer.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.5 - 6 lpm.
Scale-resistant flow straightener.
Duty flush (~60 seconds every 24 hours after the last use).
Active infrared presence detection sensor at the end of the spout optimises detection.
Chrome-plated solid brass body.
Cap fixed in place by 2 concealed screws.
PEX flexibles F3/8" with stopcocks, filters and non-return valves.
Fixing reinforced by 2 stainless steel rods.
Anti-blocking security.
Side temperature control lever with adjustable maximum temperature limiter.



TECHNICAL CHARACTERISTICS

TEMPOMATIC MIX 4 electronic mixer

Ref. 490001

Supply	230/6V plug-in mains supply
Connector	F3/8"
Technology	Electronic
Drop height	75mm
Spout length	110mm
Flow rate	3 lpm

Deck-mounted single hole catering mixer.
Swivelling tubular spout H. 255mm L. 200mm with hygienic flow straightener.
Ceramic cartridge Ø 45mm.
Flow rate 60 lpm at 3 bar.
Spout with smooth interior.
Slimline control lever.
Chrome-plated brass body and spout.
Soldered copper pipe water inlets.



TECHNICAL CHARACTERISTICS

Deck-mounted single hole mixer - 60 lpm

Ref. 5650T2

Connector	Copper tails
Drop height	255mm
Spout length	200mm
Flow rate	60 lpm
Finish	Chrome-plated brass
