Dushipaneeli pikendus 790152 Delabie Cut-to-size extension toru kaitse

Cut-to-size extension

Ref. 790152
For aluminium shower panel

For aluminium shower panel.
Protects the pipework between the top of the shower panel and the ceiling.
W. 210mm, H. 1,000mm
Extension can be cut-to-size.
Anodised aluminium.

TECHNICAL CHARACTERISTICS

Cut-to-size extension

Ref. 790152

> Working pressure : 1 to 5 bar

> Flow : 6 l/min with integrated flow limiter Anti-water-hammering device Hand-held shower on rail with chrome plated slide

> Flow time : 30 seconds (± 5 sec.)

> Hydraulic supply : G 1/2"(15x21), top or rear water inlet. For rear water inlet, we recommend to add the adaptation kit under the reference 91026. On P 50 tap NF II and thermostatic mixer tap EN 1111 (NF check valves)

> Material : Anodised aluminum profile (2.5mm thickness) Aluminum removable valve plate, peinted RAL 7005 High resistance RAL 7005 coloured ABS casings

> Functioning: Wide opening panel without the need to dismantle from the wall and shower taps on a removable valve plate

> Thermal resistance : Resistant to a temperature of 75°C for 30-minute-thermal-shocks

> Security : Anti-scald system: flow is immediately stopped if the cold water is cut off Maximum delivered temperature : pre-fixed at 38°

> Delivered with : 1/2" hoses with revolving nuts MM 1/2" (15x21) straight stop valve and 250 micron filters Fastening screw and instruction manual > Standards & approvals : Brass body in accordance with EN 1982, EN 12164, EN 12165 Chrome-plated surface treatment in accordance with EN 12540 200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227

Segistikomplekt vannile Damixa Silhouet  termostaat tilaga ja dušš liftiga matt must

Ø 45 x 170 x 185 mm
normal pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: normal pressure. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 171 mm
  Outlet height: 87 mm
  Projection: 98 mm
  Length of lever: 140 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,60
