326 x 173 x 164 mm
ca. 250 paper towels

• Paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• With deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 250 standard paper towels in zigzag- or c-fold.
  Paper size (folded): 240-250 mm x 100-115 mm.
• Accessible for refilling through lockable front flap.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Installation dimensions: 300 x 150 mm
• Mounting: With four screws on the inside, sideways.
• Delivery includes fixing material and one pack of paper towels.

• Weight (in kg): 3,4

Splashback 2400mm for CANAL wash trough
Ref. 100300

298 x 1348 x 120 mm
ca. 250 paper towels / 400 ml foam soap concentrate / 11 l

• Combination consisting of a foam soap dispenser, a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Foam soap dispenser with one-hand operated and non-drip foam soap pump.
• Designed for standard 400 ml foam soap concentrate.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 250 standard paper towels in zigzag fold.
  Paper size (folded): 240-250 mm x 100-115 mm.
• Inspection slots to indicate fill level.
• Accessible for refilling through lockable front flap with fall protection.
• Waste bin equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
• Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With eight screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material, first fill with soap and one pack of paper towels.

• Weight (in kg): 14,9
