298 x 448 x 170 mm
23 l

• Waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Equipped with removable fabric stand bag in polypropylene, washable. Capacity approx. 23 l.
• Fabric stand bag replaces garbage bag.
• Mounting: With two screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 3,8

Ø 30 x 125 mm
projection 90 mm

• Tabletop soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• Design height: 128 mm
  Outlet height: 57 mm
  Projection: 75 mm
• Non-drip soap pump with 500 ml soap bottle in plastics and pressure valve in stainless steel.
• Designed for standard liquid soaps.
• Refillable from above through detachable top part with bayonet lock.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 21-25 mm,
  surface thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material.

• Weight (in kg): 0,9

Ø 30 x 86 mm
projection 76 mm

• Tabletop disinfectant dispenser in chrome-plated brass.
• Solid body in brass; visible surfaces high-gloss chrome-plated.
• Design height:86 mm
  Outlet height: 68 mm
  Projection: 76 mm
• Non-drip disinfectant pump with 500 ml disinfectant bottle in plastics and pressure valve in brass.
• Also available with 250 ml or 1000 ml containers in plastics.
• 500 ml container in stainless steel as an option for a surcharge.
• Designed for standard disinfectants.
• Refillable from above by unscrewing the top part.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 22-26 mm,
  surface thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material.

• Weight (in kg): 0,7
