350 x 448 x 210 mm
1 paper roll

• Sensor paper roll dispenser, mains-operated, in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed with tapered glossy surface at the bottom.
  Further available surfaces: see below.
• With touch-free operated, capacitive sensor technology, sensor distance approx. 3.5 cm. Paper length and idle time adjustable.
  Mains-operated 230 V / 50 Hz; power rating 7 Watt; mains cable on site. TÜV/GS-tested and certified.
• Designed for one paper roll with dimensions:
  Width 215 mm, outer diameter max. 180 mm, inner diameter 50 mm.
• Inspection slot to indicate fill level, residual roll function allows a reserve roll to be inserted before residual roll is completely used up.
• Accessible for refilling through lockable door.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes in the back wall.
• Delivery includes fixing material and first fill with one paper roll.

• Weight (in kg): 10,3

Ø 45 x 283 x 185 mm
low pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 283 mm
  Outlet height: 199 mm
  Projection: 98 mm
  Length of lever: 140 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm, surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and three flexiblen, stainless steel covered connecting tubes.

• Weight (in kg): 2,00
