80 x 298 x 120 mm
950 ml tank

• Disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• All-stainless steel housing with rounded vertical corners. Visible surfaces satin finished and brushed. Further available surfaces: see below.
• One-hand operated disinfectant pump with 950 ml tank.
• Tank with large, lockable refill opening.
• Designed for standard disinfectants for hands.
• Note: Not approved for medical areas.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, hinged housing.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 1,1

170 x 170 x 100 mm

• Waste disposal frame in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel construction; visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Mounting: Insert and glue into cutout.
• Installation dimensions: 150 x 130 mm

• Weight (in kg): 0,7

326 x 173 x 164 mm
ca. 250 paper towels

• Paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• With deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 250 standard paper towels in zigzag- or c-fold.
  Paper size (folded): 240-250 mm x 100-115 mm.
• Accessible for refilling through lockable front flap.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Installation dimensions: 300 x 150 mm
• Mounting: With four screws on the inside, sideways.
• Delivery includes fixing material and one pack of paper towels.

• Weight (in kg): 3,4
