Automatne kummikute pesur düüsiga, 12V, 50Hz

automatic washing system for wellingtons with jets - 12V, 50Hz

AMO 01 is a stainless steel automatic washing system for wellingtons with sensor-controlled water nozzles. When stepping into the washing chamber of the system (scanning zone) water starts to flow from the nozzles automatically and wellingtons are cleaned of dirt. Water stops flowing with a certain time delay after the foot has been removed from the scanning zone.
AMO 01 is designed for a single pipe inlet of pre-mixed water from the circulation or water pre-mixed by means of a thermostatic valve.
The AMO 01 automatic washing system is intended mainly for operations with slight shoe contamination where quick washing at maximum water savings is guaranteed.

Package contents

• body of the washing machine
• photocell head
• nozzles – 8 pcs
• electromagnetic valves 2 pcs
• corner valves with filter
• connecting hoses

automatic washing system for soles with rotary brushes - 230V, 50Hz

RMP 02 is a stainless steel sensor-controlled washing system with rotary brushes for wellingtons. A built-in photocell sensor reacts to the user holding the handrail. The electromagnetic valve switches on, opens the water inlet, the brushes start to rotate and the circular jet injection of the disinfecting lotion is carried out. After placing the foot with the wellington on the grid in between the rotary brushes, the sole is cleaned by means of the horizontal brush. There is a CENTRAL/STOP button on the handrail for emergency switch-off.
The washing system is intended for free standing installation on the floor. Imperfections in the floor are balanced out by four adjustable hobs. The construction of the system allows the outlet to be placed above floor level. Large pieces of dirt are collected by a sieve, which can be easily cleaned. The sieve and brush can be taken out without using a tool.
The RMP 02 washing system, with its easy maintenance, is mainly intended for operations where quick removal of mechanical dirt from wellingtons is required.
The canister with disinfecting solution is not part of the delivery.

Package contents

• body of the washing machine
• removable grid
• electronics with photocell
• rotary brush
• hand brush
• jerican holder
• priming hose
• adjustable supporting legs
• central stop button

• Set up water inlet as per picture
• Set up outlet G 6/4” via effluvial cover
• Set up cable for power supply – 230 V, 50 Hz

> Working pressure : 1 to 5 bar

> Flow : 3 l/min with integrated flow limiter High quality anti-limescale aerator Anti-water-hammering design

> Hydraulic supply : G 3/8" (12x17) - Cold or premixed water > Power supply : Integrated 6V CRP2 lithium battery

> Material and colour finish : Injected molded metal body and cover Body: Chrome finishing Top cover: Black Chrome finishing

> Thermal resistance : Resistant to a temperature of 75°C for 30-minute-thermal-shocks

> Security : Anti-overflow security time: 30 seconds Anti-blocking system preventing the water to flow continuously

> Delivered with : 1 Brass clamping nut 1 Gasket and 1 Washer 1 Hose with revolving nut 1 Stop valve MM G 3/8" (12x17) 1 Filter gasket 1 Self-adhesive sticker Instruction manual > Standards & approvals : Brass body in accordance with NF EN1982, EN12164, NF EN 12165 200-hour neutral salt spray resistant (NSS) in accordance with NF ISO 9227
