Ukse lukukate 6mm (sisemine) D Line FAT AISI 316 Ø70mm roostevaba must

Ø70 mm (2,7")

Height: 6 mm (0,2")

Center - center distance (between screw fixings): 38/27 mm (1,5"/1")

Together with British designer Tom Dixon we’ve created FAT, a new line of hardware pieces.

Our Ø70mm Fat escutcheon w/PZ hole for the inside of an exterior door (ie. a front door),  is enduringly crafted in the highly resilient AISI 316 stainless steel preferred by d line and enhanced by a 20-year product guarantee.

The Fat collection comprises a lever handle, key escutcheon and thumb turn, as well as a door knocker, pull handle, flush pull and door stop. Like the rest of the d line portfolio, each piece is minimalist enough to be timeless in its design, its beauty coming from its rounded profile and inflated silhouette, rather than from superfluous details.

Tom Dixon uses the word ‘fat’ to imply generosity and softness of form. The result lacks any trace of sharpness or angularity and is a collection of pumped-up pieces that are simply ‘fatter’ than the norm.

The collection is available in charcoal, electric blue, polished brass and our signature satin stainless steel.

To achieve the collection’s aesthetic, Tom Dixon has magnified the silhouette of each piece’s ‘normal’ aesthetic. That’s why the diameter of our Fat lever roses and escutcheons are Ø70mm. This means, that our Fat lever handle, escutcheons and thumb turns will match lock cases where the backset minus the rebate is a minimum of 40mm. The center distance between the lever handle and escutcheon/thumb turn should also be a minimum of 71mm. For further information, please contact us.

350 x 448 x 210 mm
1 paper roll

• Sensor paper roll dispenser, battery-powered, in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed with tapered glossy surface at the bottom.
  Further available surfaces: see below.
• With touch-free operated, capacitive sensor technology, sensor distance approx. 3.5 cm. Paper length and idle time adjustable.
  Battery-powered with four standard 1.5 V Mono/LR20/12 A batteries.
• Designed for one paper roll with dimensions: Width 215 mm, outer diameter max. 180 mm, inner diameter 50 mm.
• Inspection slot to indicate fill level, residual roll function allows a reserve roll to be inserted before residual roll is completely used up.
• Accessible for refilling through lockable door.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes in the back wall.
• Delivery includes fixing material and first fill with one paper roll.

• Weight (in kg): 10,3

Korpus

Äravool

Raam

kassett

Newicon Brabantia prügikast 12l pedaaliga vaikselt sulguv Mineral Cosy BrownPEDAL BIN NEWICON
