> Working pressure :

1 to 5 bar

> Flow :

6 l/min at 3 bar with integrated flow limiter Anti-water-hammering design

> Flow time :

Adjustable by washer 30 second timer (-10/+5 seconds)

> Hydraulic supply :

Inlet M G 1/2" (15x21) - Cold or premixed water

> Thermal resistance :

Resistant to a temperature of 75°C for 30 minute thermal shock

> Security :

Patented anti-blocking "S" system to avoid the water to flow continuously

> Delivered with :

1 Cross-partition control (15 to 300 mm thick) 1 Tap P 500 S® for shower
Shower head with 17° or 25° directional grid 2 washers for flow time adjustment

1 Flat gasket
1 Nut 1/2'' (15x21) Instruction manual

> Standards & approvals :

Brass body in accordance with EN 1982, EN 12164, EN 12165 200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
