300 x 58 x 40 mm

• Towel rail in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished.
  Further available surfaces: see below.
• Two concealed anti-theft wall disc mountings.
• Holder diameter 16 mm
  Towel rail diameter 12 mm
  Distance between mounting points 300 mm
• Mounting with two screws.
• Delivery includes fixing material.

• Weight (in kg): 0,50

Korpus

Äravool

raam

ilurest

71 x 230 x 121 mm

• Disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• For mounting behind fixed mirror on site.
• One-hand operation disinfectant pump with 950 ml tank.
• Tank with large, lockable refill opening.
• Designed for standard disinfectants. Accessible for refilling through spring stop pin and by removing from below.
• Note: Not approved for medical areas.
• Wear parts can be replaced as modules.
• Mounting: With two screws through key holes and one optional anti-theft hole in the back wall.
  Depth of substructure installation: min. 160 mm
  Height above vanity unit: min. 280 mm
• Delivery includes fixing material and self-adhesive information label „Disinfectant“.

• Weight (in kg): 0,7

32 x 32 x 111 mm
projection 87 mm

• Tabletop soap dispenser, lockable, in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• Solid stainless steel body; visible surfaces satin finished. Further available surfaces: see below
• Design height: 111 mm
  Outlet height: 62 mm
  Projection: 66 mm
• Non-drip soap pump with 500 ml soap container in plastics and pressure valve in stainless steel.
• Also available with 250 ml or 1000 ml containers in plastics.
• 500 ml container in stainless steel as an option for a surcharge.
• Designed for standard liquid soaps.
• Refillable from above by unscrewing the top part, secured with hexagon socket screw.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 22-26 mm,
  surface thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material.

• Weight (in kg): 1,0
