298 x 298 x 121 mm 950 ml soap bottle / 950 ml tank disinfectant, 950 ml bottle lotion
Combination consisting of a liquid soap-, disinfectant- and lotion dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
Soap or lotion dispenser with one-hand operated and non-drip soap or lotion pump. Designed for standard 950 ml disposable bottles of liquid soap or lotion. Also refillable with large container using the plug-in tank as an option.
Disinfectant dispenser with one-hand operated disinfectant pump with 950 ml tank arranged in the middle. Designed for standard disinfectants. Note: Not approved for medical areas!
Inspection slots to indicate fill level.
Accessible for refilling through lockable, hinged housing.
Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
Wear parts can be replaced as modules.
Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
Delivery includes fixing material, first fill with soap and lotion.
Weight (in kg): 5,3
AVAILABLE SURFACES
ORDER NUMBERS
satin finished (standard)
727730
highly polished
731730
(coloured) plastic powder - coating
728730
Suggested text for specifications:
Combination consisting of a liquid soap, disinfectant and lotion dispenser in stainless steel (AISI 316L) for surface mounting. All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Soap or lotion dispenser with one-hand operated and non-drip soap or lotion pump. Designed for standard 950 ml disposable bottles of liquid soap or lotion. Disinfectant dispenser with one-hand operated disinfectant pump with 950 ml tank arranged in the middle. Designed for standard disinfectants. Inspection slots to indicate fill level. Accessible for refilling through lockable, hinged housing. Keyed alike cylinder lock in corrosion-resistant zinc die-casting. Delivery includes fixing material, first fill with soap and lotion.
Wall-mounted eye wash station with manual control includes: 304 stainless steel basin Ø 250mm, green powder-coated finish. Two spray heads fitted with protective caps in shock-resistant green ABS; will eject automatically when activated. 1/4-turn, nickel-plated brass valve opens and closes quickly. Water flow is activated by the hand control. The eye wash will continue to operate when the hand control is released. The water flow will stop when the hand control is pulled towards the user. Flow rate 20 lpm at 3 bar. Aerators with stainless steel double filters. Water supply M1/2". Pipework made from galvanised steel, grey powder-coated finish. Hand control made from galvanised steel, green powder-coated finish. Wall-mounted on a brass plate (screws not included.) Supplied with identification sign for first aid equipment: "Eye Wash"
