DESCRIPTION

HEMI inset round washbasin Ø 385mm - Ref. 120490

Round washbasin for recessed installation from above or below.
Basin internal diameter: 385mm.
Cut-out diameter: 400mm for installation from above, 380mm for installation from below.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 0.8mm
One-piece, seam-free pressed bowl.
Rounded edges prevent injury.
Supplied with 1 1⁄4" waste.
Without overflow.
CE marked. Complies with European standard EN 14688.
Weight: 1.6kg.

Range: Timed flow single tap for shower

Ref: 27400 - PRESTO DL 400 SE® single tap with straight stop valve

> Working pressure :

1 to 5 bar

> Flow :

8 l/min at 3 bar with integrated flow limiter (+ additional 6l/mn limiter) Anti-water-hammering design
Fixed shower head with anti-limescale spikes

> Flow time :

30 seconds (± 5 sec.)

> Hydraulic supply :

G 1/2" (15x21) Top water inlet with straight stop valve For cold or premixed water

> Material and colour finish :

Injected molded metal body and cover
Extruded cover in aluminium (magnesium-silicon alloy 6060)

> Thermal resistance :

Resistant to a temperature of 75°C for 30-minute-thermal-shocks

> Security :

Patented anti-blocking "S" system to avoid the water to flow continuously

> Delivered with :

VBA screws and nylon plugs Additional 6l/mn limiter
M G 1/2" - FG3/4" stop valve and filter Instruction manual

> Standards & approvals :

Acoustic class I
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
