Silmadush Broen , läbi pinda kinnitusega
Kui oled leidnud endale sobiva toote, klõpsa lihtsalt LISA KORVI,
mine OSTUKORVI, vali TELLI, täida andmed ja vali tarnemeetod.
Nii lihtne see ongi – ost ootab vaid paari klõpsu!
Kaubamärk:
Ühik: tk
Tarneaeg: 7-14 päeva
Müüja: PEGU OÜ
For orders from European Union countries, please send a price inquiry to our email. To calculate the shipping cost, please provide the address. For companies, include your VAT number.
8 l/min
341,60 €
Min. working pressure: 1.5 bar for all Eye Showers
S P E C I F I C AT I O N S
Handle: Metal, BROEN-LAB POLYCOAT powder coated
with media indication according to EN13792
Hose nozzle: Removable/external G3/4 thread, metalHeadwork: Diaphragm type
Opening/closing function: 1 1/2 x 360°Temperature range: 0-90°C
Max. working pressure: 10 bar / 147 psi
Test pressure: 1 x working pressure
Weight: 0.9 kg
MATERIALS WITH MEDIA CONTACT
Metals: Stainless Steel, AISI 316Diaphragm: PTFE
Rubber: EPDM
ORDERING INFORMATION
For standard configuration please refer to the item numbers below.
Wall mounted double eye wash
Wall mounted eye shower with a two 45° angled heads, incl. 1.5m inlet hose.
Trigger operated including a built-in check valve and FLOWFIX for regulation of water flow (14 l/min).
Description
Wall Mount Double Eye Wash
SAFETY
Improved trigger lock
Improved activation of the shower
OPERATION
Stay-open dust cap
Light weight
Well-balanced construction
Better spray pattern
RELIABILITY
Easy-to-clean spray head
Anti-limescale design and material choice
Improved functionality
Longer lifetime
Wall-mounted safety shower
Ref. 9108
Wall-mounted safety shower with manual control includes:
Frost-free system as standard.
Circular shower head Ø 250mm in green, shock-resistant ABS.
1/4-turn, nickel-plated brass valve opens and closes quickly.
Water flows simply by pulling on the triangular handle.
The flow will continue even when the handle is released.
The flow will stop when the handle is returned to its original position.
Flow rate 70 lpm at 1 bar dynamic pressure (120 lpm at 3 bar dynamic pressure).
Water supply F1".
Pipework made from galvanised steel, grey powder-coated finish. Triangular pull handle in green powder-coated brass.
Supplied with identification sign for first aid equipment: "Safety Shower".
For cross wall installation, with recessed supply, or for mounting on a false ceiling (we recommend a 1" mounting bracket).
TECHNICAL FEATURES
Wall-mounted safety shower
Ref. 9108
| Supply | F1" |
|---|---|
| Height | 450mm |
| Length | 625mm |
| Flow rate | 120 lpm at 3 bar dynamic pressure |
| Finish | Epoxy |
