298 x 1348 x 120 mm
ca. 250 paper towels / sensor with 950 ml soap bottle / 11 l

• Combination consisting of a sensor liquid soap dispenser, a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Sensor liquid soap dispenser with EWAR® eModule touch-free operated soap pump.
• Designed for standard 950 ml disposable bottles of liquid soap or hand lotion.
• Also refillable with large container using the plug-in tank as an option.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 250 standard paper towels in zigzag fold.
  Paper size (folded): 240-250 mm x 100-115 mm.
• Inspection slots to indicate fill level.
• Accessible for refilling through lockable front flap with fall protection.
• Waste bin equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
• Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
• eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  Power supply available as an option.
• Wear parts can be replaced as modules.
• Mounting: With eight screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material, batteries, first fill with soap and one pack of paper towels.

• Weight (in kg): 15,8

Duššiiste seinale

soap dispenser - paper towel dispenser -waste bin

• Professional washroom equipment for your office or at home.
• Optimal hygiene for you and your visitors.
• Compact, timeless design.
• Made from robust, germ-reducing and easy-care stainless steel. Visible surfaces satin finished und brushed.
• Designed for standard liquid soaps and paper towels. Delivery includes first fills.
• Easy assembly: for gluing or screwing. Delivery includes fixing material.
• ID No. WH-Kit: 727 344 - also available as individual devices; order numbers see below.
• Quality products Made in Germany

Liquid soap dispenser WH2
Dimensions: 70 x 172 x 90 mm

• One-hand operated and non-drip soap pump with 200 ml tank.
• Tank with large, lockable refill opening.
• Designed for standard liquid soaps or hand lotions.
  Not suitable for disinfectants!
• Inspection slot to indicate fill level.
• Accessible for refilling through hinged housing with spring-clip locking.
• ID No. 727 345

Paper towel dispenser WH5
Dimensions: 260 x 225 x 120 mm

• Designed for approx. 300 standard paper towels in zigzag fold.
  Paper size (folded): 240-250 mm x 100-115 mm.
• Inspection slot to indicate fill level.
• Refillable from the top.
• ID No. 727 346

Waste bin WH15
Dimensions: 260 x 400 x 150 mm

• Capacity appox. 15 l.
• Equipped with internal holder for standard garbage bags.
• ID No. 727 347

• Weight (in kg): 6,3
