435 x 148 x 148 mm
for 1 paper roll Ø 125 x 390 mm

• Paper roll dispenser for nappy changer in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Designed for one standard paper roll with dimensions:
  Outer diameter max. 125 mm
  Width: max. 390 mm
  Core diameter: min. 40 mm.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, hinged housing.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 3,8

298 x 396 x 150 mm

• Hot air hand dryer in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed with tapered glossy surface at the bottom.
  Further available surfaces: see below.
• Touch-free, low-failure capacitive sensor technology, sensor distance 0–30 cm, power cut-off after 30 s drying time.
• Low noise.
• SEV-tested and certified.
• Supply voltage 230 V, 50 Hz
  Power rating 2000 Watt
  Heater power 1915 Watt
  Motor power 85 Watt
  Air output 258 m³/h
• Blower unit can be replaced as module.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material and device plug.

• Weight (in kg): 7,2
