298 x 298 x 121 mm
950 ml soap bottle / 950 ml tank disinfectant / 950 ml bottle lotion

• Sensor combination consisting of a sensor liquid soap-, disinfectant- and lotion dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Sensor soap or lotion dispenser with EWAR® eModuletouch-free operated and non-drip soap and lotion pump.
  Designed for standard 950 ml disposable bottles of liquid soap or lotion. Also refillable with large container using the plug-in tank as an option
• Sensor disinfectant dispenser with EWAR® eModule touch-free operated disinfectant pump with 950 ml tank arranged in the middle. Designed for standard disinfectants.
• Note: Not approved for medical areas.
• Inspection slots to indicate fill level.
• Accessible for refilling through lockable, hinged housing.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  Power supply available as an option.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material, batteries and first fill with soap and lotion.

• Weight (in kg): 6,4

Thema handle CC160mm. Available in brushed, polished and black. H2566

Ø 38 x 62 mm
projection 90 mm

• Tabletop soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• Design height: 62 mm
  Outlet height: 37 mm
  Projection: 74 mm
• Non-drip soap pump with 500 ml soap bottle and pressure valve in stainless steel.
• Also available with 250 ml or 1000 ml containers.
• 500 ml container in stainless steel as an option for a surcharge.
• Designed for standard liquid soaps.
• Refillable from above by unscrewing the top part.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 22-26 mm,
  surface thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material.

• Weight (in kg): 0,7
