R/V teras AISI304 , max rull d275mm

200 x 300 x 185 mm
ca. 250 paper towels

• Paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; visible surfaces satin finished and brushed. Further available surfaces: see below.
• Paper guided through a non-wearing, constant pressure spring mechanism for easy paper removal.
• Designed for approx. 250 standard paper towels in zigzag- or c-fold.
  Paper size (folded): 240-250 mm x 100-115 mm.
• Accessible for refilling through spring flaps from the top.
• Installation dimensions: 266 x 155 mm
• Mounting: With four screws from below with brackets.
• Delivery includes fixing material and one pack of paper towels.

• Weight (in kg): 3,9

148 x 448 x 120 mm
950 ml tank

• Disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
• One-hand operated and non-drip disinfectant pump with 950 ml tank.
• Tank with large, lockable refill opening.
• Designed for standard disinfectants.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, removable front panel with fall protection.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts and front panel can be replaced as modules.
• Installation dimensions: 150 x 450 x 110 mm
• Mounting: With four screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material and first fill with soap.

• Weight (in kg): 3,0

80 x 245 x 220 mm
500 ml bottle

• Disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• Half-open stainless steel housing; visible surfaces satin finished and brushed.
• Elbow-operated disinfectant pump, can be set to different levels and autoclaved.
• Designed for standard 500 ml disposable bottles of disinfectant.
• Accessible for refilling from the front side. Lockable cover plate in stainless steel as an option for a surcharge.
• Further accessories for a surcharge: drip tray
• Wear parts can be replaced as modules.
• Mounting: With three screws through holes in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 1,0

Ø 30 x 86 mm
projection 90 mm

• Tabletop disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• Solid stainless steel body; visible surfaces satin finished. Further available surfaces: see below.
• Design height:86 mm
  Outlet height: 68 mm
  Projection: 76 mm
• Non-drip disinfectant pump with 500 ml disinfectant bottle in plastics and pressure valve in stainless steel.
• Also available with 250 ml or 1000 ml containers in plastics.
• 500 ml container in stainless steel as an option for a surcharge.
• Designed for standard disinfectants.
• Refillable from above by unscrewing the top part.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 22-26 mm,
  surface thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material.

• Weight (in kg): 0,7
