COMBINATION ELECTRONIC PAPER ROLL DISPENSER BATTERY POWERED AND WASTE BIN WP 5451
448 x 1348 x 220 mm 1 paper roll / 48 l
Combination consisting of a sensor paper roll dispenser (battery-powered) and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
Paper roll dispenser with touch-free operated, capacitive sensor technology, sensor distance approx. 3.5 cm. Paper length and idle time adjustable. Battery-powered with four standard 1.5 V Mono/LR20/12 A batteries.
Designed for one paper roll with dimensions: Width 215 mm, outer diameter max. 180 mm, inner diameter 50 mm.
Inspection slot to indicate fill level, residual roll function allows a reserve roll to be inserted before residual roll is completely used up.
Waste bin equipped with removable mesh basket. Capacity approx. 48 l.
Accessible through lockable doors.
Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
Wear parts and front panels can be replaced as modules.
Installation dimensions: 450 x 1350 x 210 mm (when fully fitted).
Mounting: With six screws in wall opening through fixing holes in the side walls.
Delivery includes fixing material and first fill with one paper roll.
Weight (in kg): 25,8
AVAILABLE SURFACES
ORDER NUMBERS
satin finished (standard)
727541
highly polished
731541
(coloured) plastic powder - coating
729541
Suggested text for specifications:
Combination consisting of a sensor paper roll dispenser (battery-powered) and a waste bin in stainless steel (AISI 304) for flush mounting. All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Paper roll dispenser with touch-free operated, capacitive sensor technology. Paper length and idle time adjustable. Battery-powered with four standard 1.5 V Mono/LR20/12 A batteries. Designed for one paper roll with dimensions: Width 215 mm, outer diameter max. 180 mm, inner diameter 50 mm. Inspection slot to indicate fill level. Waste bin equipped with removable mesh basket. Capacity approx. 48 l. Accessible through lockable doors. Keyed alike cylinder locks in corrosion-resistant zinc die-casting. Delivery includes fixing material and first fill with one paper roll.
Double toilet roll holder in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished. Further available surfaces: see below.
Designed for two standard toilet rolls with dimensions: Outer diameter max. 125 mm Width max. 100 mm Core diameter min. 38 mm
Two anti-theft two-point rosette wall mountings.
Can be mounted pointing right or left.
Holder diameter 20 mm Roll holder diameter 12 mm
Mounting with four screws.
Delivery includes fixing material.
Weight (in kg): 0,80
AVAILABLE SURFACES
ORDER NUMBERS
satin finished (standard)
700252
highly polished
731252
Suggested text for specifications:
Double toilet roll holder in solid stainless steel (AISI 303), satin finished, for surface mounting. Two anti-theft two-point rosette wall mountings. Can be mounted pointing right or left. Delivery includes fixing material.
Märksõnadeks aegumatu minimalistik disain ja kõrge kvaliteet. d line tootevalik pakub nn täislahendust esikust vannitoani – aksessuaarid vannituppa ja ühiskondlikesse WC-desse, ukse- ja aknalingid, uksereelingud, uksekellad, mööblikäepidemed, WC- indikaatorid jt uste sulused ja tarvikud.
Materjal happekindel roostevaba teras (AISI 316), mis sobib ka avalikku ruumi, nagu linna- ja tööstusinterjöör, avamere keskkond jm. Viimistlus poleeritud ja harjatud.
d line Cup dispenser wall mounted produced in AISI 316 satin or polished stainless steel. The design is characterized by simplicity and functionality, and the minimalistic exterior hides advanced technic that ensures the products strength and durability for many years. d line as Roholmsvej 12F DK-2620 Albertslund www.dline.com info@dline.com Product care: d line products are produced in the highest quality stainless steel, marine grade, AISI 316. To sustain the unique d line surface appearance please follow the below instructions: Wash down the surfaces using soapy water or mild detergent Always thoroughly rinse off with clean water To complete the cleaning procedure dry/polish the surfaces with a soft dry cloth Please do not use scouring powder, steel wool, chloride based detergents or other aggressive cleaning products as these may damage the surface. If spots or corrosion appear on the surface it is not due to the stainless steel quality, but to impurities in the environment, aggressive conditions or improper or insufficient cleaning
The d line sanitary range by Knud Holscher combines cleanness in its lines with cleanliness in its function, and unlike our hardware collection of individual yet complimentary items, this series consists of fittings that form a cohesive whole.
Wherever they appear, our sanitary products can be flexibly combined yet always provide the same uniform impression. In their technical design, installation and maintenance are key focuses, to meet the need for impeccable hygiene no matter how long they live in a space.
Simple and modular, the d line sanitary range’s AISI 316 rust-resistant, non-corrosive, marine quality steel stands up to the high humidity levels of the bathroom, while its subtle curved edges and functional circular hole details are a nod to the bend in our first ever products, the L and U lever handles by Knud Holscher.
Both internally and externally, every detail of every d line sanitary piece is rigorously tested for seamless functioning so that it endures. Then, assisted by the most cutting-edge machinery in our field, each is expertly crafted by hand.
The d line sanitary range by Knud Holscher combines cleanness in its lines with cleanliness in its function, and unlike our hardware collection of individual yet complimentary items, this series consists of fittings that form a cohesive whole.
Wherever they appear, our sanitary products can be flexibly combined yet always provide the same uniform impression. In their technical design, installation and maintenance are key focuses, to meet the need for impeccable hygiene no matter how long they live in a space.
Simple and modular, the d line sanitary range’s AISI 316 rust-resistant, non-corrosive, marine quality steel stands up to the high humidity levels of the bathroom, while its subtle curved edges and functional circular hole details are a nod to the bend in our first ever products, the L and U lever handles by Knud Holscher.
Both internally and externally, every detail of every d line sanitary piece is rigorously tested for seamless functioning so that it endures. Then, assisted by the most cutting-edge machinery in our field, each is expertly crafted by hand.
