REMS Swing - torude painutamine seal, kuhu neid paigaldatakse, kuni Ø 32mm. Ülikiire töö tänu praktilisele mitmefunktsioonili- sele hoovale kiir-ettenihkeks ja kiirtagastuseks. Hammaslatt karastatud terasest. Ühe käe torupainutaja Ø 10-32mm, Ø⅜-⅞", kuni 90°. Pehmed vasktorud Ø 10-22mm, Ø ⅜–⅞", s ≤ 1 mm, pehmed kaetud vasktorud Ø 10–18 mm, Ø ⅜–⅝", s ≤ 1 mm, pehmed pressfitting-süsteemide kaetud süsinikterastorud Ø 12–18 mm, s ≤ 1,2 mm, pehmed täppisterastorud Ø 10–18 mm, s ≤ 1 mm, komposiit- torud Ø 14–32 mm. Kuni Ø 26 mm, ajamiseade, painutussegmendid, liugurikandja S Ø 10–26 mm koos liuguritega, tugevas terasplekist kastis/kohvris. Kuni Ø 32 mm, ajamiseade, painutussegmendid (Ø12, 15, 18, 22), 2 liugurikandjat Ø 10–26 mm ja Ø 32 mm koos liuguritega, tugevas kohvris.
Tabletop soap dispenser, lockable, in robust, germ-reducing and easy-care stainless steel (AISI 316L).
Solid stainless steel body; visible surfaces satin finished. Further available surfaces: see below
Design height: 111 mm Outlet height: 62 mm Projection: 66 mm
Non-drip soap pump with 500 ml soap container in plastics and pressure valve in stainless steel.
Also available with 250 ml or 1000 ml containers in plastics.
500 ml container in stainless steel as an option for a surcharge.
Designed for standard liquid soaps.
Refillable from above by unscrewing the top part, secured with hexagon socket screw.
Wear parts can be replaced as modules.
Installation dimensions: Ø 22-26 mm, surface thickness max. 40 mm.
Mounting: With one counternut.
Delivery includes fixing material.
Weight (in kg): 1,0
AVAILABLE SURFACES
ORDER NUMBERS
satin finished (standard)
923376
highly polished
931376
Suggested text for specifications:
Tabletop soap dispenser, lockable, in stainless steel (AISI 316L) for counter mounting. Solid stainless steel body; visible surfaces satin finished. Non-drip soap pump with 500 ml soap container in plastics and pressure valve in stainless steel. Designed for standard liquid soaps. Refillable from above by unscrewing the top part, secured with hexagon socket screw. Delivery includes fixing material.
Dimensions: (with container) 65 x 359 x 130 mm Design height: 111 mm Outlet height: 62 mm Projection: 66 mm
