Be-Line® matte white straight grab bar Ø 35mm, L. 900mm Ref. 511909W
Be-Line® grab bar Ø 35mm, for people with reduced mobility. For use as a handrail or grab bar for WCs, showers or baths. Aluminium tube, 3mm thick. Solid aluminium fixing points. Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip. Matte white powder-coated aluminium finish provides a good visual contrast with the wall. Uniform surface for easy maintenance and hygiene. 38mm gap between the bar and the wall:minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance. Concealed fixings. Supplied with stainless steel screws Ø 8 x 70mm for concrete walls. 900mm centre-to-centre. Tested to over 200kg. Maximum recommended user weight: 135kg.
Technical features
Be-Line® matte white straight grab bar Ø 35mm, L. 900mm Ref. 511909W
COMBINATION PAPER TOWEL DISPENSER AND WASTE BIN WP 5010
298 x 1048 x 220 mm ca. 250 paper towels / 32 l
Combination consisting of a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
Designed for approx. 250 standard paper towels in zigzag fold. Paper size (folded): 240-250 mm x 100-115 mm.
Inspection slot to indicate fill level.
Accessible for refilling through lockable front flap with fall protection.
Waste bin equipped with removable mesh basket. Capacity approx. 32 l. Accessible through lockable door.
Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
Wear parts and front panels can be replaced as modules.
Installation dimensions: 300 x 1050 x 210 mm (when fully fitted).
Mounting: With six screws in wall opening through fixing holes in the side walls.
Delivery includes fixing material and one pack of paper towels.
Weight (in kg): 13,4
AVAILABLE SURFACES
ORDER NUMBERS
satin finished (standard)
727528
highly polished
731528
(coloured) plastic powder - coating
729528
Suggested text for specifications:
Combination consisting of a paper towel dispenser and a waste bin in stainless steel (AISI 304) for flush mounting. All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Paper towel dispenser with deep-drawn paper removal opening, filling quantity approx. 250 paper towels. Inspection slot to indicate fill level. Accessible for refilling through lockable front flap with fall protection. Waste bin equipped with removable mesh basket. Capacity approx. 32 l. Accessible through lockable door. Keyed alike cylinder locks in corrosion-resistant zinc die-casting. Delivery includes fixing material and one pack of paper towels.
