435 x 148 x 148 mm
for 1 paper roll Ø 125 x 390 mm

• Paper roll dispenser for nappy changer in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Designed for one standard paper roll with dimensions:
  Outer diameter max. 125 mm
  Width: max. 390 mm
  Core diameter: min. 40 mm.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, hinged housing.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 3,8

91 x 259(221) x 98 mm

• Liquid soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• For mounting behind fixed mirror on site.
• One-hand operated and non-drip soap pump.
• Designed for standard 500 ml or 950 ml disposable bottles of liquid soap or hand lotion. Accessible for refilling through spring stop pin and by removing from below.
• Also refillable with large container using the plug-in tank as an option.
• Wear parts can be replaced as modules.
• Mounting: With two screws through key holes and one optional anti-theft hole in the back wall.
  Depth of substructure installation: min. 130 mm
  Height above vanity unit: min. 220(250) mm
• Delivery includes fixing material, self-adhesive information label „Soap“ and first fill with soap.

• Weight (in kg): 1,5
