Kätepaberidosaator sensoriga Wagner Ewar 1+1 roll pattareiga R/V teras satiin
ELECTRONIC TOUCH-FREE PAPER ROLL DISPENSER WITH RESERVE ROLL BATTERY POWERED WP 1401
350 x 580 x 210 mm 1 paper roll + 1 reserve roll
Choose product variant
Sensor paper roll dispenser with cabinet for reserve roll, battery-powered, in robust, germ-reducing and easy-care stainless steel (AISI 304).
All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed with tapered glossy surface at the bottom. Further available surfaces: see below.
With touch-free operated, capacitive sensor technology, sensor distance approx. 3.5 cm. Paper length and idle time adjustable. Battery-powered with four standard 1.5 V Mono/LR20/12 A batteries.
Designed for one paper roll and one reserve roll with dimensions: Width 215 mm, outer diameter max. 180 mm, inner diameter 50 mm.
Inspection slot to indicate fill level, residual roll function allows a reserve roll to be inserted before residual roll is completely used up.
Accessible for refilling through lockable door.
Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
Wear parts can be replaced as modules.
Mounting: With four screws through key holes in the back wall.
Delivery includes fixing material and first fill with one paper roll.
Weight (in kg): 12,4
AVAILABLE SURFACES
ORDER NUMBERS
satin finished (standard)
733260
highly polished
732260
(coloured) plastic powder - coating
728260
Suggested text for specifications:
Sensor paper roll dispenser with cabinet for reserve roll, battery-powered, in stainless steel (AISI 304) for surface mounting. All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed with tapered glossy surface at the bottom. With touch-free operated, capacitive sensor technology. Paper length and idle time adjustable. Battery-powered with four standard 1.5 V Mono/LR20/12 A batteries. Designed for one paper roll and one reserve roll with dimensions: Width 215 mm, outer diameter max. 180 mm, inner diameter 50 mm. Inspection slot to indicate fill level. Accessible for refilling through lockable door. Residual roll function allows a reserve roll to be inserted before residual roll is completely used up. Keyed alike cylinder lock in corrosion-resistant zinc die-casting. Delivery includes fixing material and first fill with one paper roll.
Peeglikapp 4 funktsiooniga: peegel, elektrooniline kraan, seebidosaator ja paberrätikute dosaator. Valmistatud mattmustast melamiinist ja 304 roostevabast terasest. Kasutajasõbralik ja hügieeniline, tänu infrapunasensoritele aktiveeruvad kraan ja seebidosaator automaatselt. Lihtne paigaldus: üks elektriühendus ja veeliitmik (M3/8") sobivad nii seinale kui ka kapi sisemusse. LED-valgustusega peegel ja vandalismikindel disain.
Mirror cabinet with 4 functions
Ref. 510205
Mirror cabinet with 4 functions: mirror, electronic tap, soap dispenser and paper towel dispenser. Designer cabinet with a matte black melamine and 304 stainless steel finish. Touch-free for improved hygiene: tap and soap dispenser activated automatically when hands are detected by infrared sensor. Quick and easy to install: - A single electrical connection for all the elements: mains supply with 230V / 50-60Hz. - Connects to the water supply from the top or from inside the cabinet. - Water connection in M3/8". - Concealed fixings. Mirror cabinet supplied with stainless steel screws for concrete or reinforced wood. - Adjustable hinges. Unit with 4 functions: 4mm thick glass mirror and black glass strip with illuminated pictograms. Automatic soap dispenser: - No-waste pump dispenser - Large capacity tank: 5 litres. - Suitable for vegetable-based liquid soap with a maximum viscosity of 3,000 mPa.s or specific foam soap. Electronic basin tap*: - Reduced stagnation valve. - Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 to 6 lpm. - Scale-resistant flow straightener. - Duty flush (~60 seconds every 24 hours after the last use). - Stopcock. Paper towel dispenser: - Dispenses one sheet at a time. - Dimensions: 120 x 275 x 360mm. - Contents: 500 sheets. Basin lit by the LED strip. Vandal-resistant model with standard DELABIE key. Anti-blocking: stops automatically if used continuously. Internal storage shelf. Several cabinets can be installed side-by-side to create a mirror wall: linking screws are provided. Dimensions: 600 x 223 x 1,000mm. Weight: 28kg.
TECHNICAL CHARACTERISTICS
Mirror cabinet with 4 functions
Ref. 510205
Supply
Mains: 230V / 50-60Hz
Connector
M3/8"
Technology
Electronic
Height
1,000mm
Depth
223mm
Width
600mm
Flow rate
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 to 6 lpm
