Be-Line corner grab bar Ø 35mm for WCs, showers or baths.
Use as a shower rail and to support the user in an upright position.
Helps and secures entry and movement in the shower also with getting in and out of the bath.
Helps with the transfer from a wheelchair to the toilet seat.
Dimensions: 695 x 695mm.
Aluminium tube thickness 3mm. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Metallised anthracite powder-coated aluminium provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall: minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
Tested to over 200kg. Maximum recommended user weight: 135kg.

Technical features

Be-line corner grab bar 2 walls, anthracite
Ref. 511941C

Be-Line corner grab bar Ø 35mm for showers.
Use as a shower rail and to support the user in an upright position.
Helps and secures entry and movement in the shower also with getting in and out of the bath.
Helps with the transfer from a wheelchair to the toilet seat.
Dimensions: 695 x 695mm.
Aluminium tube thickness 3mm. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Matte white powder-coated aluminium finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall: minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
Tested to over 200kg. Maximum recommended user weight: 135kg.

Technical features

Be-line corner grab bar 2 walls, white
Ref. 511941W

Be-Line sliding shower head holder.
Metallised anthracite.
Support for tilting shower head.
Easy-to-operate ergonomic grip to adjust the height of the shower head holder.
Slides by pressing the grip or pulling on the flexible hose.

Technical features

Be-Line sliding shower head holder
Ref. 511911C

Be-Line sliding shower head holder.
Matte white.
Support for tilting shower head.
Easy-to-operate ergonomic grip to adjust the height of the shower head holder.
Slides by pressing the grip or pulling on the flexible hose.

TECHNICAL FEATURES

Be-Line sliding shower head holder
Ref. 511911W

Metallised anthracite shelf for grab bars, for showers.
Installed against the all on the bar.
Anti-theft locking screw.
Ideal for shower gel or soap.
2 hooks for gloves.

TECHNICAL FEATURES

Metallised anthracite shelf for grab bars for showers
Ref. 511922C

White shelf for grab bars, for showers.
Installed against the all on the bar.
Anti-theft locking screw.
Ideal for shower gel or soap.
2 hooks for gloves.

TECHNICAL FEATURES

White shelf for grab bars for showers
Ref. 511922W

Be-Line metallised anthracite cover plate without fixings plate.
Conceals fixing screws when the drop-down support rail is removed.
Reduces the number of drop-down rails in a facility, allowing installation only when required.
Example: hotels or hospitals providing short-term accommodation for people with reduced mobility.

TECHNICAL FEATURES

Cover plate for Be-Line drop-down rail
Ref. 511950C

Be-Line metallised anthracite cover plate with fixings plate.
Conceals fixing screws when the drop-down support rail is removed.
Reduces the number of drop-down rails in a facility, allowing installation only when required.
Example: hotels or hospitals providing short-term accommodation for people with reduced mobility.
Supplied with stainless steel screws for concrete walls.

TECHNICAL FEATURES

Cover plate for Be-Line drop-down rail with fixings plate
Ref. 511950FC

Be-Line matte white cover plate without fixings plate.
Conceals fixing screws when the drop-down support rail is removed.
Reduces the number of drop-down rails in a facility, allowing installation only when required.
Example: hotels or hospitals providing short-term accommodation for people with reduced mobility.

TECHNICAL FEATURES

Cover plate for Be-Line drop-down rail
Ref. 511950W

Be-Line matte white cover plate with fixings plate.
Conceals fixing screws when the drop-down support rail is removed.
Reduces the number of drop-down rails in a facility, allowing installation only when required.
Example: hotels or hospitals providing short-term accommodation for people with reduced mobility.
Supplied with stainless steel screws for concrete walls.

TECHNICAL FEATURES

Cover plate for Be-Line drop-down rail with fixings plate
Ref. 511950FW

Tilting mirror with long ergonomic lever which facilitates adjustment of mirror angle from a sitting position or by wheelchair users.
For combined installation: can be used from sitting or standing position.
Quick and easy to install: just clip into place.
Anti-theft lock.
Bright white HR Nylon lever
6mm thick Securit safety glass mirror.
Mirror dimensions: 500 x 600mm.
Can be tilted up to 20°.

Technical features

Tilting mirror with long ergonomic lever
Ref. 510201N

Tilting glass mirror with handle for easy adjustment those in a seated position or in a wheelchair.
For combined installation: can be used from sitting or standing position.
Quick and easy to install: simply clip into place.
Anti-theft lock.
Metallised anthracite tab handle.
Mirror made from 6mm Securit safety glass.
Mirror dimensions: 500 x 600mm.
Can be tilted up to 20°.

TECHNICAL FEATURES

Adjustable mirror with handle
Ref. 510202C

Tilting glass mirror with handle for easy adjustment those in a seated position or in a wheelchair.
For combined installation: can be used from sitting or standing position.
Quick and easy to install: simply clip into place.
Anti-theft lock.
Metallised anthracite tab handle.
Mirror made from 6mm Securit safety glass.
Mirror dimensions: 500 x 600mm.
Can be tilted up to 20°.

Technical features

Tilting mirror with tab handle
Ref. 510202N

Be-Line drop-down support rail for people with reduced mobility.
In the lowered position use as a grab bar, as a support for standingand for assisting movement, for WCS or showers.
Allows side access in the raised position.
Removable: easy to remove with anti-theft locking system. Reduces the number of barsin a facility, allowing installation only when required.
Example: hotels or hospitals providing short-term accommodation for people with reduced mobility.
Slowed down descent. Retained in upright position.
Aluminium tube.
Rounded profile Ø 42mm with ergonomic flat front face that prevents rotation for an optimal grip.
Metallised anthracite powder-coated aluminium finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
Concealed fixings secured to wall by a 304 stainless steel plate, 5mm thick.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
Dimensions: 650 x 210 x 120mm.
Tested to over 200kg. Maximum recommended user weight: 135kg.

TECHNICAL FEATURES

Be-Line drop-down support rail, L. 650mm, anthracite
Ref. 511960C

Be-line® angled grab bar 135°, Ø 35mm, for people with reduced mobility.
For use as a handrail (horizontal part) or as a grab rail (135° part), for WCs, showers or baths.
Universal for either left or right side.
Aluminium tube thickness 3mm. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Matte white powder-coated aluminium; provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall: minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
3 fixing points prevent the hand from getting trapped and simplify installation.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
Dimensions: 220 x 220mm.
Tested to over 200kg. Maximum recommended user weight: 135kg.

Technical features

Be-line® matte white angled grab bar 135°, 220 x 220mm
Ref. 511983W

Be-Line® grab bar Ø 35mm, for people with reduced mobility.
For use as a handrail or grab bar for WCs, showers or baths.
Aluminium tube, 3mm thick. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Metallised anthracite powder-coated finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall: minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
300mm centre-to-centre.
Tested to over 200kg. Maximum recommended user weight: 135kg.

Technical features

Be-Line® anthracite straight grab bar Ø 35mm, L. 300mm
Ref. 511903C

Be-Line® straight grab bar Ø 35mm, for people with reduced mobility.
For use as a handrail or grab bar for WCs, showers or baths.
Aluminium tube, 3mm thick. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Matte white powder-coated aluminium provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall:minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
300mm centre-to-centre.
Tested to over 200kg. Maximum recommended user weight: 135kg.

Technical features

Be-Line® matte white straight grab bar Ø 35mm, L. 300mm
Ref. 511903W

Be-Line® grab bar Ø 35mm, for people with reduced mobility.
For use as a handrail or grab bar for WCs, showers or baths.
Aluminium tube, 3mm thick. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Metallised anthracite powder-coated finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall: minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
400mm centre-to-centre.
Tested to over 200kg. Maximum recommended user weight: 135kg.

Technical features

Be-Line® anthracite straight grab bar Ø 35mm, L. 400mm
Ref. 511904C

Be-Line® straight grab bar Ø 35mm, for people with reduced mobility.
For use as a handrail or grab bar for WCs, showers or baths.
Aluminium tube, 3mm thick. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Matte white powder-coated aluminium finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall: minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
400mm centre-to-centre.
Tested to over 200kg. Maximum recommended user weight: 135kg.

Technical features

Be-Line® matt white straight grab bar Ø 35mm, L. 400mm
Ref. 511904W

Be-Line® grab bar Ø 35mm, for people with reduced mobility.
For use as a handrail or grab bar for WCs, showers or baths.
Aluminium tube, 3mm thick. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Metallised anthracite powder-coated finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall: minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
500mm centre-to-centre.
Tested to over 200kg. Maximum recommended user weight: 135kg.

Technical features

Be-Line® anthracite straight grab bar Ø 35mm, L. 500mm
Ref. 511905C

Be-Line® grab bar Ø 35mm, for people with reduced mobility.
For use as a handrail or grab bar for WCs, showers or baths.
Aluminium tube, 3mm thick. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Matte white powder-coated aluminium finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall:minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
500mm centre-to-centre.
Tested to over 200kg. Maximum recommended user weight: 135kg.

Technical features

Be-Line® matte white straight grab bar Ø 35mm, L. 500mm
Ref. 511905W

Be-Line® grab bar Ø 35mm, for people with reduced mobility.
For use as a handrail or grab bar for WCs, showers or baths.
Aluminium tube, 3mm thick. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Metallised anthracite powder-coated finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall: minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
600mm centre-to-centre.
Tested to over 200kg. Maximum recommended user weight: 135kg.

Technical features

Be-Line® anthracite straight grab bar Ø 35mm, L. 600mm
Ref. 511906C

Be-Line® grab bar Ø 35mm, for people with reduced mobility.
For use as a handrail or grab bar for WCs, showers or baths.
Aluminium tube, 3mm thick. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Matte white powder-coated aluminium finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall:minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
600mm centre-to-centre.
Tested to over 200kg. Maximum recommended user weight: 135kg.

Technical features

Be-Line® matte white straight grab bar Ø 35mm, L. 600mm
Ref. 511906W

Be-Line® grab bar Ø 35mm, for people with reduced mobility.
For use as a handrail or grab bar for WCs, showers or baths.
Aluminium tube, 3mm thick. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Metallised anthracite powder-coated finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall:minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
900mm centre-to-centre.
Tested to over 200kg. Maximum recommended user weight: 135kg.

Technical features

Be-Line® anthracite straight grab bar Ø 35mm, L. 900mm
Ref. 511909C

Be-Line® grab bar Ø 35mm, for people with reduced mobility.
For use as a handrail or grab bar for WCs, showers or baths.
Aluminium tube, 3mm thick. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Matte white powder-coated aluminium finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall:minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
900mm centre-to-centre.
Tested to over 200kg. Maximum recommended user weight: 135kg.

Technical features

Be-Line® matte white straight grab bar Ø 35mm, L. 900mm
Ref. 511909W

Be-line® straight bar Ø 35mm with sliding shower head holder for people with reduced mobility.
Can be used as a vertical grab bar and a shower head rail for showers or baths.
Metallised anthracite aluminium sliding shower head holder with ergonomic locking ring.
Possible to add a sliding soap dish (order separately).
Aluminium tube thickness 3mm. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Metallised anthracite powder-coated finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall: minimal space prevents the forearm passing between the barand the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
Height: 1,050mm.
Tested to over 200kg. Maximum recommended user weight: 135kg.

Technical features

Be-line® anthracite shower grab bar with sliding shower head holder
Ref. 511946C

Be-line® straight bar Ø 35mm with sliding shower head holder for people with reduced mobility.
Can be used as a vertical grab bar and a shower head rail for showers or baths.
Matte-white sliding shower head holder with ergonomic locking ring.
Aluminium tube thickness 3mm. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Matte white powder-coated aluminium provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall: minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
Height: 1,050mm.
Tested to over 200kg. Maximum recommended user weight: 135kg.

TECHNICAL FEATURES

Be-line® white shower grab bar with sliding shower head holder
Ref. 511946W

Be-line® L-shaped grab bar for showers or baths.
Helps the user stand and move safely in the shower or bath.
Use as a shower rail by adding a shower head holder and/or soap dish.
Can be installed with upright bar on the left or right.
Aluminium tube thickness 3mm. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Metallised anthracite powder-coated finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall: minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
Dimensions: 1,130 x 450mm.
Tested to over 200kg. Maximum recommended user weight: 135kg.

Be-line® L-shaped grab bar for showers or baths.
Helps the user stand and move safely in the shower or bath.
Use as a shower rail by adding a shower head holder and/or soap dish.
Can be installed with upright bar on the left or right.
Aluminium tube thickness 3mm. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Matte white powder-coated aluminium provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall: minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
Dimensions: 1,130 x 450mm.
Tested to over 200kg. Maximum recommended user weight: 135kg.

TECHNICAL FEATURES

Be-line® L-shaped grab bar, matte white, H. 1,130mm
Ref. 511971W

Be-line® L-shaped grab bar for showers or baths.
Helps the user stand and move safely in the shower or bath.
Use as a shower rail by adding a shower head holder and/or soap dish.
Aluminium tube thickness 3mm. Solid aluminium fixing points.
Rounded profile Ø 35mm with ergonomic flat front face that prevents rotation for an optimal grip.
Metallised anthracite powder-coated finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
38mm gap between the bar and the wall: minimal space prevents the forearm passing between the bar and the wall, reducing the risk of fracture in case of loss of balance.
Concealed fixings.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
Dimensions: 750 x 450mm.
Tested to over 200kg. Maximum recommended user weight: 135kg.

Technical features

Be-line® L-shaped grab bar, anthracite, H. 750mm
Ref. 511970C
