400 x 298 x 120 mm
ca. 500 paper towels / 500 ml soap bottle

• Combination consisting of a liquid soap dispenser and a paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Liquid soap dispenser with one-hand operated and non-drip soap pump.
• Designed for standard 500 ml disposable bottles of liquid soap or hand lotion.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 500 standard paper towels in zigzag fold. Paper size (folded): 240-250 mm x 100-115 mm.
• Inspection slots to indicate fill level.
• Accessible for refilling through lockable front flap with fall protection.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material, first fill with soap and one pack of paper towels.

• Weight (in kg): 4,4

Seebidosaatori eModule (ilma patareideta, Wagner Ewar)

Infrapunaanduriga moodulit saab kasutada mitmes EWAR® seebidosaatoris ja kombinatsioonides seebidosaatoritega.
Alternatiivselt võib kasutada kaubanduslikult saadaval olevaid 500 ml või 950 ml seebipudeleid või 200 ml mahutit.
Tööpingepinge: 3V (2 LR14 patareid), kuni 3000 aktiveerimist.
Patareipesa asub paremal ja on hõlpsasti ligipääsetav ilma seebimahutit eemaldamata.
3V vooluadapter patareideta kasutamiseks on saadaval lisatarvikuna.
Andurimoodul ja pump on modulaarse kujundusega ning neid saab tööriistadeta vahetada.
Hooldusrežiim: andurimoodul lülitub välja, kui seadme korpus avatakse.
Hoiatusnäidik madala patarei taseme kohta.
Tuvastusvahemik: umbes 5 cm (mõõdetakse automaatselt).
Andur tuvastab valguse muutusi (kaitseb väärkasutuse eest, näiteks anduripinna katmisega).
Kaal: 0,22 kg.

• PP101e-7
• PP102e-1
• PP102e-7
• PP102e-7S
• WP101e
• WP101e-7
• WP102e
• WP102e-1
• WP102e-7
• WP102e-7S
• WP102e-7T
• WP173e
• WP173e-1
• WP173e-7
• WP174e
• WP174e-2
• WP174e-7
• WP208e
• WP208e-7
• WP500e
• WP510e
• WP550e
• WP575e
• WP585e
• WP585e-7
• WP600e
• WP650e

• Infra-red sensor module can be used in several EWAR® soap dispensers and combinations with soap dispensers.
• Alternatively, can be operated with commercially available 500 ml or 950 ml soap bottles or with 200 ml tank.
• Operating voltage 3V, (2 LR14 baby batteries), for up to 3000 actuations.
• Battery compartment on the right is easily accessible without removing the soap tank.
• 3V mains supply for batteryless operation available as an accessory.
• Sensor module and pump in modular design and can be replaced without tools.
• Service mode: sensor module switches off when device housing is opened.
• Warning display for low battery level.
• Detection range approx. 5 cm (is measured automatically).
• Sensor detects light changes (protects against misuse e.g. by masking the sensor surface).
• Weight: 0,22 kg

298 x 396 x 150 mm

• Hot air hand dryer in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed with tapered glossy surface at the bottom.
  Further available surfaces: see below.
• Touch-free, low-failure capacitive sensor technology, sensor distance 0–30 cm, power cut-off after 30 s drying time.
• Low noise.
• SEV-tested and certified.
• Supply voltage 230 V, 50 Hz
  Power rating 2000 Watt
  Heater power 1915 Watt
  Motor power 85 Watt
  Air output 258 m³/h
• Blower unit can be replaced as module.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material and device plug.

• Weight (in kg): 7,2
