d line products are produced in the highest quality stainless steel, marine grade, AISI 316. To sustain the unique d line finish appearance please follow the below instructions: ● Wash down the surfaces using soapy water or mild detergent ● Always thoroughly rinse off with clean water ● To complete the cleaning procedure dry/polish the surfaces with a soft dry cloth
Please do not use scouring powder, steel wool, chloride based detergents or other aggressive cleaning products as these may damage the surface. If spots or corrosion appear on the surface it is not due to the stainless steel quality, but to impurities in the environment, aggressive conditions or improper or insufficient cleaning
Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
Version: normal pressure. Operating pressure 2–6 bar.
Solid stainless steel body; visible surfaces satin finished. Further available surfaces: see below.
High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
Neoperl® air bubble spray M22 x 1 mm.
Design height: 171 mm Outlet height: 87 mm Projection: 98 mm Length of lever: 40 mm
Wear parts can be replaced as modules.
Installation dimensions: Ø 33-40 mm Surface thickness max. 40 mm
Mounting: With one counternut.
Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
Weight (in kg): 1,60
AVAILABLE SURFACES
ORDER NUMBERS
satin finished (standard)
924266
highly polished
931266
Suggested text for specifications:
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: normal pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 171 x 155 mm Outlet height 87 mm Projection 98 mm Length of lever 40 mm
Damixa termostaatsegisti dušile CORE ZERO 57400 matt must
KÜSI HINDA PROJEKTILE!
Standardomadused:
Keraamiline tööorgan Põletuskaitsega (38oC) Veekulu max.16 l/min Standardne tsentrite vahe 150 mm Veesäästu funktsioon Eco-Klik Varustatud 3/4" ilukatete ja ekstsentrikutega.
