Labori Valamud
Sees 492x282 (vajab põhjaklappi 97B0073)
Broen Lab PP labori valamu 552x400x235 (PxLxK) valge
Sees 492x282 (vajab põhjaklappi 97B0073)
PRODUCT NUMBER 97B0810
FOR WASTE CONNECTION
S P E C I F I C AT I O N S
Temperature range: 0-80°C
Standard colour: black (other colours available on request ) Net weight: 5.4 kg
Dimensions: external 807 x 469 x 330mm (tolerance ± 1mm)
The largest polypropylene sink offered, it is suitable for cleansing of larger items. Very widely used in island benches and teacher benches.
Broen Stabilet elektroonilise juhtmedega termostaat
PRINCIPLE SKETCH STABILET® EL / STABILINE® EL
1. Outlet including infrared sensor. Reacts when an object is in front of the spout.
2. Electronic box including transformer from mains to 12V DC.
3. STABILET® EL or STABILINE® EL valve. SPECIFICATIONS, ELECTRONIC BOX Mains voltage: 220V, 50 Hz phase, neutral and earth. Other voltage on request Operating voltage: 12V DC. Short circuit safety transformer Power consumption: Idling: 3 W. / Working: 3.5 W Built-in control of max. flow time of 45 sec Adjustable operating distance, min. 5 cm, max. 50 cm Waterproof plastic box and cable entries, IP 65 Cable length: From electronic box to STABILET EL®/ STABILINE EL®: 100 cm From electronic box to sensor: (spout)100 cm Screws and plugs included
PP labori valamu 418x216x320 (PxLxK) (vajab põhjaklappi 97B0073)
S P E C I F I C AT I O N S
Temperature range: 0-80°C
Standard colour: black (other colours available on request) Net weight: 1.4 kg
Dimensions: bxternal 418 x 316 x 220mm (tolerance ± 1mm)
Injection moulded from polypropylene copolymer resin, with
a self-draining base. Designed for mounting on top or underside of the work benches.
SECURITHERM BIOCLIP thermostatic sink mixer
Ref. H9611P
Sequential: opens and closes with cold water.
Supplied with 2 removable BIOCLIP stainless steel spouts L. 136mm.
Anti-scalding failsafe: immediate shut-off if cold or hot water supply fails.
Securitouch thermal insulation prevents burns.
No risk of cross flow between hot and cold water.
No non-return valves on the inlets.
Scale-resistant sequential thermostatic cartridge.
Temperature control: cold water up to 40°C. Temperature limiter set at 40°C.
Thermal or chemical shocks are possible.
Body and spout with smooth interiors and low water volume.
Flow rate regulated at 7 lpm.
No manual contact thanks to Hygiene control lever L. 146mm.
Mixer with 150mm centres, supplied with in-line STOP/CHECK connectors ideal for hospitals.
Chrome-plated brass body.
TECHNICAL CHARACTERISTICS
SECURITHERM BIOCLIP thermostatic sink mixer
Ref. H9611P| Connector | M1/2" |
| Technology | SECURITHERM BIOCLIP sequential, Securitouch |
| Height | 141mm |
| Width | 184mm |
| Spout length | 136mm |
| Flow rate | 7 lpm |
| Temperature limiter | 40°C |
| Finish | Chrome-plated brass |
675,00 €
Bucket sink in stainless steel for wall mounting. Supplied with stainless steel wall panel, supporting bracket and 3 1/2" x 2" waste with plug and overflow.
Laborikraan Broen-Lab Sensoriga tööpinnale. S=200mm.220V
Pöördepiiraja 110 kraadi. Valge (RAL0008500)
Broen-LAB
Specifications
Aerator, with flow limitation 5 L/min
Sensor operated opening and closing function with bi-stabile technology
110° limited swivel spout
Temperatur range: 5-65° (41°F - 149°F) Max. working pressure: 10 bar/145 psi
Surface
Chemical resistant Polyester Based Surface treatment, UV-resistent.
BROEN-LAB colour: 2700 (RAL colour: 0008500)
Material with media contact
Brass
Rubber, EPDM
Silicone based lubricant PPSU
SS
PA
SPX Hose
Electrical connection
Adaptor: 100-240 V AC 50/60 Hz Battery: 6 V Lithium
Hose
Supplied with hoses.
Hose (1) on the picture is mandatory and included. Hose (2) on the picture is optional. See in the table below which options you have for hose (2)*.
For further options contact BROEN-LAB
Laborisegisti Broen-Lab Sensorsegisti tööpinnale. S=200mm.220V
Pöördepiiraja 110 kraadi. Valge (RAL0008500)
Temp.regulaator FCP sensoriga jooksutorule.
Paindühendused 700mm,G1/2" mutter
Broen-LAB
Sensor Tap with temperature adjustor M30x1.5 mm mounting
Specifications
Aerator, with flow limitation 5 L/min
Sensor operated opening and closing function with bi-stabile technology
110° limited swivel spout
Non-return valve integrated in valvehouse
Temperatur range: 5-65° (41°F - 149°F)
Max. working pressure: 10 bar/145 psi
Surface
Chemical resistant Polyester Based Surface treatment, UV-resistent.
BROEN-LAB colour: 2700 (RAL colour: 0008500)
Material with media contact
Brass
Rubber, EPDM
Silicone based lubricant PPSU
SS
PA
SPX Hose
Electrical connection
Adaptor: 100-240 V AC 50/60 Hz Battery: 6 V Lithium
Hose
Supplied with hoses.
Hose (1) and (2) on the picture are mandatory and included. The hoses (3) on the picture are optional. See in the table below which options you have for the hoses (3)*.
For further options contact BROEN-LAB
Sees 290x290 (vajab põhjaklappi 97B0073)
81,33 €
81,33 €
76,25 €
