540 x 946 x 135 mm
vertical version

• Nappy changer in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed, handle strip with glossy surface.
  Further available surfaces: see below.
• Easy to open and close with maintenance free lifting mechanism supported by gas struts.
• Table surface in grey polypropylene, molded, without any visible fixtures.
• TÜV-tested and certified according to
  DIN EN 1221-1: 2013
  DIN EN 1221-2: 2013
  AfPS GS 2014: 01 PAK
  Load capacity 15 kg, test load 150 kg;
  approved for public and private use.
• Wear parts can be replaced as modules.
• Mounting: With four screws through fixing holes in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 26,7

298 x 1348 x 120 mm
ca. 250 paper towels / sensor with 950 ml soap bottle / 11 l

• Combination consisting of a sensor liquid soap dispenser, a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Sensor liquid soap dispenser with EWAR® eModule touch-free operated soap pump.
• Designed for standard 950 ml disposable bottles of liquid soap or hand lotion.
• Also refillable with large container using the plug-in tank as an option.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 250 standard paper towels in zigzag fold.
  Paper size (folded): 240-250 mm x 100-115 mm.
• Inspection slots to indicate fill level.
• Accessible for refilling through lockable front flap with fall protection.
• Waste bin equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
• Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
• eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  Power supply available as an option.
• Wear parts can be replaced as modules.
• Mounting: With eight screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material, batteries, first fill with soap and one pack of paper towels.

• Weight (in kg): 15,8

298 x 780 x 310 mm
ca. 36 l

• Nappy bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed, at the top highly polished. Further available surfaces: see below.
• Equipped with removable hygiene bin. Capacity approx. 36 l. Designed for standard garbage bags. Accessible through lockable door.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• On the top one-hand operated, by 180 ° swiveling, odor-reducing insertion sluice made of polypropylene.
• Wear parts can be replaced as modules.
• With four rubber feet for floor installation.

• Weight (in kg): 13,0

Käterätikuivati on valmistatud messingist. (brass)

Полотенцесушители выполнены из латуни

Käterätikuivati elektrielemendi kaitse IP67

Käterätikuivati elektrikätikuivatile IP44-IP55

Степень защиты электрического элемента IP67

Степень защиты электрического полотенцесушителя IP44-IP55

Maksimaalne temperatuur 60°C

максимальная температура 60°C

Võimalikud viimistlused Chroom +...%

Возможные покрытия Chroom +...%
