Keraamiline HOME pissuaar Alessi LAUFEN radariga Sanela integreeritud adapter 230V/AC
SLP 25RZ
Urinal Alessi with a radar flushing unit and integrated power supply, 230 V AC
Characteristics
easy installation
whole flushing unit is placed behind the urinal
system reacts only on the direct use of the urinal (it analyses changes, which are proceeded inside of the urinal, when a liquid is flowing through)
adjustable flushing time 0,5 - 15,5 s
parameters adjustment by remote control SLD 04 without the necessity to dismantle the urinal from the wall (acoustic setting indication)
automatic flushing after each 6 hours non-use
possibility to regulate a water flow by the angle valve
radar flushing unit recharges a water to the siphon after each flushing
Order number
01255
Code
SLP 25RZ
Supply specification
SLP 25RZ - Supply No. 01255 - ceramic urinal with radar flushing unit, plastic mounting box with brass screw coupling, electromagnetic valve and ball valve, inlet fitting with a rubber sealing, mounting set. siphon, power supply
Technical information
Dimension of mounting box: 140 x 140 x 75 mm Operating voltage: 230V AC/50Hz Recommended flow pressure: 0,1 - 0,6 MPa Rate of flow: 12 l/min. (inf. data) Water inlet: male thread G 3/4“ Water outlet: inlet fitting with a rubber seal
