Professionaalne santehnika R-V teras AISI304
2-ne Valamu jalaga 1200x700, kõrgus 850mm , R/V teras
Нержавеющая большегрузная двойная мойка на ножках, 1200 x 700 x 850 мм
Характеристики
- stainless steel bulk double-sink with a sheating
- without a tap hole (could be made to order)
- possibility of fine plane regulation by the regulation screws on the supporting legs
- possibility to order inner sinks in dimensions: 400 x 300 x 200 mm/ 400 x 400 x 250 mm/ 400 x 400 x 200 mm
- available also in the length 1400 mm
- material CrNi 18/10 (AISI-304)
- brushed finish
- different dimensions could be made to order
| Арт. № | 93160 |
| Название | SLUN 16 |
Automatne kummikute pesur düüsiga, 12V, 50Hz
automatic washing system for wellingtons with jets - 12V, 50Hz
AMO 01 is a stainless steel automatic washing system for wellingtons with sensor-controlled water nozzles. When stepping into the washing chamber of the system (scanning zone) water starts to flow from the nozzles automatically and wellingtons are cleaned of dirt. Water stops flowing with a certain time delay after the foot has been removed from the scanning zone.
AMO 01 is designed for a single pipe inlet of pre-mixed water from the circulation or water pre-mixed by means of a thermostatic valve.
The AMO 01 automatic washing system is intended mainly for operations with slight shoe contamination where quick washing at maximum water savings is guaranteed.
Package contents
- body of the washing machine
- photocell head
- nozzles – 8 pcs
- electromagnetic valves 2 pcs
- corner valves with filter
- connecting hoses
| Radius of sensor | 0 – 0,4 m |
| Water inlet | G 1/2“ |
| Water pressure | 0,3 – 1,0 MPa |
| Outlet | d = 32 mm |
| Inner dimensions of the trough | 250 x 400 x 280 mm |
| Electricity protection | IP 55 |
| Power supply | 12 V, 50 Hz |
| Power requirement | 10 VA |
| Source of power supply | ZAC 1/20 (max. 2 x AMO 01) |
| ZAC 1/50 (max. 5 x AMO 01) | |
| Weight | 18 kg |
- Set up water inlet as per picture
- Set up outlet d = 32 mm
- Set up cable for power supply – 12 V, 50 Hz from source of power supply ZAC
automatic washing system for soles with rotary brushes - 230V, 50Hz
RMP 02 is a stainless steel sensor-controlled washing system with rotary brushes for wellingtons. A built-in photocell sensor reacts to the user holding the handrail. The electromagnetic valve switches on, opens the water inlet, the brushes start to rotate and the circular jet injection of the disinfecting lotion is carried out. After placing the foot with the wellington on the grid in between the rotary brushes, the sole is cleaned by means of the horizontal brush. There is a CENTRAL/STOP button on the handrail for emergency switch-off.
The washing system is intended for free standing installation on the floor. Imperfections in the floor are balanced out by four adjustable hobs. The construction of the system allows the outlet to be placed above floor level. Large pieces of dirt are collected by a sieve, which can be easily cleaned. The sieve and brush can be taken out without using a tool.
The RMP 02 washing system, with its easy maintenance, is mainly intended for operations where quick removal of mechanical dirt from wellingtons is required.
The canister with disinfecting solution is not part of the delivery.
Package contents
- body of the washing machine
- removable grid
- electronics with photocell
- rotary brush
- hand brush
- jerican holder
- priming hose
- adjustable supporting legs
- central stop button
| Radius of sensor | 0,5 m |
| Water inlet | G 1/2“ |
| Water pressure | 0,1 – 1,0 MPa |
| Outlet | G 6/4” |
| Electricity protection | IP 55 |
| Power supply | 230 V, 50 Hz |
| Power requirement | 370 W |
| Water temperature | max. 42°C |
| Weight | 41 kg |
- Set up water inlet as per picture
- Set up outlet G 6/4” via effluvial cover
- Set up cable for power supply – 230 V, 50 Hz
RMO 02
automatic washing system for wellingtons
RMO 02 is a stainless steel sensor-controlled washing system with rotary brushes for wellingtons. A built-in photocell sensor reacts to the user holding the handrail. The electromagnetic valve switches on, opens the water inlet, the brushes start to rotate and the circular jet injection of the disinfecting lotion is carried out. After placing the foot with the wellington on the grid in between the rotary brushes, the sole is cleaned by means of the horizontal brush and the leg portion is cleaned by means of two vertical brushes. The system is automatically switched off when the user releases the handrail. There is a CENTRAL/STOP button on the handrail for emergency switch-off.
The washing system is intended for free standing installation on the floor. Imperfections of the floor are balanced out by four adjustable hobs. The construction of the system allows the outlet to be placed above the floor level.
The RMO 02 washing system, with its easy maintenance, is mainly intended for operations where quick removal of mechanical dirt from wellingtons is required.
The canister with disinfecting solution is not part of the delivery.
Package contents
- body of the washing machine
- removable grid
- electronics with photocell
- three rotary brushes
- jerican holder
- priming hose
- adjustable supporting legs
- central stop button
| Radius of sensor | 0,7 m |
| Water inlet | G 1/2“ |
| Water pressure | 0,1 – 1,0 MPa |
| Outlet | G 6/4” |
| Electricity protection | IP 55 |
| Power supply | 230 V, 50 Hz |
| Power requirement | 370 W |
| Water temperature | max. 42°C |
| Weight | 95 kg |
- Set up water inlet as per picture
- Set up outlet G 6/4” via effluvial cover
- Set up cable for power supply – 230 V, 50 Hz
Wall-mounted cleaners' sink
Ref. 182400
Wall-mounted cleaners' sink with splashback.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 0.9mm.
Seam-free, pressed bowl.
Deep sink.
Smooth surface.
Rounded edges prevent injury.
Supplied with 1½" waste .
Without overflow.
Supplied with fixing elements and splashback.
Weight: 4.6kg.
TECHNICAL FEATURES
Wall-mounted cleaners' sink
Ref. 182400
| Height | 404mm |
|---|---|
| Length | 370mm |
| Width | 460mm |
| Thickness | 0.9mm |
| Finish | Polished satin 304 stainless steel |
Delabie majahoidja põranda valamu viduariga R/V teras AISI304
Floor-standing janitorial unit
Ref. 180140
Floor-standing janitorial unit.
Bacteriostatic 304 stainless steel. Polished satin finish.
Stainless steel thickness: 1.0mm.
Smooth surface for easy cleaning.
Adjustable feet height up to 25mm.
With tap hole Ø 35mm on right side.
Supplied with 1 ¼" waste for washbasin and 1½" for disposal sink. Without overflow.
Hinged stainless steel bucket grid.
Weight: 22kg.
TECHNICAL FEATURES
Floor-standing janitorial unit
Ref. 180140
| Height | 900mm |
|---|---|
| Length | 600mm |
| Width | 500mm |
| Thickness | 1.0mm |
| Finish | 304 polished satin stainless steel |
Floor-standing disposal sink
Ref. 180150
Floor-standing disposal sink.
Bacteriostatic 304 stainless steel. Polished satin finish.
Stainless steel thickness: 1.0mm.
One-piece pressed bowl, seam-free.
Smooth surface is easy to clean.
Adjustable feet height up to 40mm.
Supplied with 1½" waste. Without overflow.
Hinged stainless steel bucket grid.
Weight: 10.6kg.
TECHNICAL FEATURES
Floor-standing disposal sink
Ref. 180150
| Height | 475/495mm |
|---|---|
| Length | 480mm |
| Width | 480mm |
| Thickness | 1.0mm |
| Finish | 304 polished satin stainless steel |
Wall-mounted plaster sink
Ref. 180130
Wall-mounted plaster sink.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.5mm.
Smooth surface and flat edges for easy cleaning.
Suitable for hospitals, healthcare establishments and leisure centres.
Supplied with removable plaster basket with lid to filter plaster debris.
Can be installed in 2 ways: bowl on the right or bowl on the left.
Waste outlet 1 ½".
Supplied with fixing elements.Weight: 17kg.
TECHNICAL FEATURES
Wall-mounted plaster sink
Ref. 180130
| Height | 390mm |
|---|---|
| Length | 600mm |
| Width | 1000mm |
| Thickness | 1.5mm |
| Finish | 304 polished satin stainless steel |
Floor-standing XL P disposal sink
Ref. 182070
Floor-standing disposal sink.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.5mm.
Smooth surface is easy to clean.
Concealed perimetral flushing system.
Horizontal or vertical water inlet: Ø 55mm.
Horizontal or vertical water outlet: Ø 100mm.
Supplied with PVC pipe.
Concealed drainage: shrouded sink.
Quick and easy to install: 2 access panels
with theft prevention TORX security screws.
Hinged stainless steel bucket grid.
Weight: 16kg.
TECHNICAL FEATURES
Floor-standing XL P disposal sink
Ref. 182070
| Height | 450mm |
|---|---|
| Length | 445mm |
| Width | 410mm |
| Thickness | 1.5mm |
| Finish | 304 polished satin stainless steel |
Floor-standing XL P disposal sink
Ref. 182060
Floor-standing disposal sink.
Bacteriostatic 304 stainless steel.
Stainless steel thickness: 1.5mm.
Polished satin finish.
Smooth surface is easy to clean.
Concealed perimetral flushing system.
Horizontal or vertical water inlet: Ø 55mm.
Horizontal or vertical water outlet: Ø 100mm.
Supplied with PVC pipe.
Concealed drainage: shrouded sink.
Quick and easy to install: 2 access panelswith theft prevention TORX security screws.
Hinged stainless steel bucket grid.
Weight: 16kg.
TECHNICAL FEATURES
Floor-standing XL P disposal sink
Ref. 182060
| Height | 450mm |
|---|---|
| Length | 445mm |
| Width | 410mm |
| Thickness | 1.5mm |
| Finish | 304 polished satin stainless steel |
Wall-mounted XL S disposal sink
Ref. 182160
Wall-mounted disposal sink.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.5mm
Smooth surface for easy cleaning.
Concealed perimetral flushing system.
Horizontal water inlet: Ø 55mm.
Recessed horizontal waste outlet: Ø 100mm.
Concealed drainage: shrouded sink.
Quick and easy to install from the front thanksto a stainless steel mounting frame.
Hinged stainless steel bucket grid.
Supplied with fixing elements.
Weight: 15kg.
TECHNICAL FEATURES
Wall-mounted XL S disposal sink
Ref. 182160
| Height | 410mm |
|---|---|
| Length | 500mm |
| Width | 410mm |
| Thickness | 1.5mm |
| Finish | 304 polished satin stainless steel |
Wall-mounted disposal sink
Ref. 180170
Wall-mounted disposal sink.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.5mm
Smooth surface for easy cleaning.
Waste outlet 1 ¼". Waste not included.
Hinged stainless steel bucket grid.
Without overflow.
Supplied with fixing elements.
Weight: 5.1kg.
TECHNICAL FEATURES
Wall-mounted disposal sink
Ref. 180170
| Height | 195mm |
|---|---|
| Length | 390mm |
| Width | 360mm |
| Thickness | 1.2mm |
| Finish | 304 polished satin stainless steel |
FACIL wall-mounted washbasin
Ref. 121800
Wall-mounted washbasin, 360x390mm.
Basin internal diameter: 320mm.
Clean and simple design.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.2mm.
Rounded edges prevent injury.
With Ø 35mm on the right.
Supplied with 1 ¼" waste.
Without overflow.
Supplied with fixing elements.
CE marked. Complies with European standard EN 14688.
Weight: 4.1kg.
GENOU wall-mounted hand washbasin
Reference: 180330
CCTP description
Wall-mounted, knee-operated hand washbasin.
Bacteriostatic 304 stainless steel. Polished satin finish.
Stainless steel thickness: 1.2mm
Rounded edges prevent injury.
Supplied with swan neck spout and time flow
tap with 7 second time flow.
Supplied with 1 ¼" waste.
Without overflow.
Supplied with fixing elements.
CE marked. Complies with European standard EN 14688.
Weight: 5kg.
MINIMAL corner washbasin
Ref. 121550
Wall-mounted corner washbasin (90° angle).
Basin internal diameter: 320mm.
Clean and simple design.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.2mm
Rounded edges prevent injury.
With Ø 35mm central tap hole.
Supplied with 1 ¼" waste.
Without overflow.
Supplied with fixing elements.
CE marked. Complies with European standard EN 14688.
Weight: 4kg.
Surgical scrub-up trough with high upstand
Ref. 186000
Wall-mounted surgical scrub-up trough with 450mm upstand.
Suitable for hospitals and healthcare facilities.
Bacteriostatic 304 stainless steel. Polished satin finish. Stainless steel thickness: 1.2mm.
Length 1,400mm, 2 services. Without tap hole.
Smooth surface and rounded inside edges for easy cleaning.
"Hygiene+" design: reduces niches where bacteria can develop, concealed trap, easy to clean.
Drainage on the right. Without overflow.
Supplied with fixing elements.Weight: 34.4kg.
Surgical scrub-up trough with high upstand
Ref. 187000
Wall-mounted surgical scrub-up trough with 450mm upstand.
Suitable for hospitals and healthcare facilities.
Bacteriostatic 304 stainless steel. Polished satin finish. Stainless steel thickness: 1.2mm.
Length 2,100mm, 3 services. Without tap hole.
Smooth surface and rounded inside edges for easy cleaning.
"Hygiene+" design: reduces niches where bacteria can develop, concealed trap, easy to clean.
Drainage on the right. Without overflow.
Supplied with fixing elements.Weight: 48.5kg.
Surgical scrub-up trough with high upstand
Ref. 185000
Wall-mounted surgical scrub-up trough with 450mm upstand.
Suitable for hospitals and healthcare facilities.
Bacteriostatic 304 stainless steel. Polished satin finish. Stainless steel thickness: 1.2mm.
Length 700mm, 1 service. Without tap hole.
Smooth surface and rounded inside edges for easy cleaning.
"Hygiene+" design: reduces niches where bacteria can develop, concealed trap, easy to clean.
Drainage on the right. Without overflow.
Supplied with fixing elements.Weight: 20.3kg.
REDO wall-mounted washbasin
Ref. 121710
Wall-mounted washbasin.
Basin internal diameter: 320mm.
Clean and simple design.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.2mm.
Rounded edges prevent injury.
With central tap hole Ø 35mm.
Supplied with 1 ¼" waste.
Without overflow.
Supplied with fixing elements.
CE marked. Complies with European standard EN 14688.
Weight: 3kg.
TECHNICAL FEATURES
REDO wall-mounted washbasin
Ref. 121710
| Height | 150mm |
|---|---|
| Length | 375mm |
| Width | 430mm |
| Thickness | 1.2mm |
| Finish | 304 polished satin stainless steel |
Floor-standing SXL hand washbasin
Ref. 180300
Floor-standing, foot-operated hand washbasin.
Can be wall-mounted and/or floor-standing.
Bacteriostatic 304 stainless steel. Polished satin finish. Stainless steel thickness: 1.2mm.
Supplied with swan neck spout and time flow tap with 7 second time flow.
Easy to maintain: access panel at the front.
Supplied with 1¼" waste.
Without overflow.
Supplied with fixing elements.
CE marked. Complies with European standard EN 14688.
Weight: 10kg.
Wall-mounted SXS electronic hand washbasin WRAS
Ref. 18431015
Wall-mounted hand washbasin with electronic control.
Bacteriostatic 304 stainless steel.
Stainless steel thickness: 1.2mm.
Rounded edges prevent injury.
Without splashback.
Supplied with WRAS approved electronic tap with integrated battery and solenoid valve, a TMV3 and WRAS approved thermostatic mixing valve and a chrome-plated brass soap-dispenser.
1¼" waste included. Without overflow.
Water savings: flow rate pre-set at 3 lpm.
Maximum hygiene: no manual contact with tap, reduced stagnation solenoid valve, duty flush prevents bacterial development.
Supplied with fixings.
CE marked. Complies with European standard EN 14688.
Weight: 4.1kg.
Wall-mounted SXS electronic hand washbasin
Ref. 184310
Wall-mounted hand washbasin with electronic control.
Bacteriostatic 304 stainless steel.
Stainless steel thickness: 1.2mm.
Rounded edges prevent injury.
Without splashback.
Supplied with battery-operated electronic mixer with integrated battery and solenoid valve, and chrome-plated brass soap-dispenser.
1¼" waste included. Without overflow.
Water savings: flow rate pre-set at 3 lpm.
Maximum hygiene: no manual contact with tap, reduced stagnation solenoid valve, duty flush prevents bacterial development.
Supplied with fixings.
CE marked. Complies with European standard EN 14688.
Weight: 4.1kg.
Valamu R/V terasest
Garaazi/koristusruumi jaoks
Intra GUB2 R/V teras koristaja valamu, ämberresti ja pritsmisplekiga
Valamu R/V terasest
Garaazi/koristusruumi jaoks
Valamu R/V terasest
Garaazi/koristusruumi jaoks
Bucket sink in stainless steel for wall mounting. Supplied with stainless steel wall panel, supporting bracket and 3 1/2" x 2" waste with plug and overflow.
Intra seinale kinniatav majandusvalamu VK 480x385x190mm, R/V teras
Wall hung utility sink in stainless steel. Supplied with fixing brackets.
Intra seinale kinniatav majandusvalamu VK 655x505x250mm, R/V teras
Wall hung utility sink in stainless steel. Supplied with fixing brackets.
