Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
Version: normal pressure. Operating pressure 2–6 bar.
Solid stainless steel body; visible surfaces satin finished. Further available surfaces: see below.
High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
Neoperl® air bubble spray M21 x 1 mm.
Design height: 171 mm Outlet height: 87 mm Projection: 98 mm Length of lever: 140 mm
Wear parts can be replaced as modules.
Installation dimensions: Ø 33-40 mm Surface thickness max. 40 mm
Mounting: With one counternut.
Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
Weight (in kg): 1,60
AVAILABLE SURFACES
ORDER NUMBERS
satin finished (standard)
924276
highly polished
931276
Suggested text for specifications:
Single-lever basin tap in stainless steel (AISI 303) for counter mounting. Version: normal pressure. Solid stainless steel body; visible surfaces satin finished. Ceramic mixer cartridge with adjustable temperature limit setting. Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.
Dimensions: Ø 52 x 171 x 185 mm Outlet height 87 mm Projection 98 mm Length of lever 140 mm
