>  Flow:

maximum: 43 l/min at 3 bars minimum: 4 l/min at 3 bars

>  Temperature :

Factory setting: 38°C
Temperature, hot water inlet: 85°C max
Minimum differential temperature: 15°C (Between hot water inlet and mixed outlet) Temperature control plan: 20 to 65°C at 3 bar
Mixed Temperature Stability: +/- 2°C from 37 to 42°C for a flow range from 12 to 47L/mn

>  Hydraulic supply :

G 1/2" (15x21) Inlet & Outlet
Red tag for hot water, and blue tag for cold water

>  Thermal resistance :

Designed to withstand thermal shocks at temperatures over 75°C during 30 min

>  Security :

Anti-scald system: flow is immediately stopped if the cold water is cut off Internal temperature blocker

>  Delivered with :

2 Filter gaskets
2 NF check valves Instruction manual

>  Standards & approvals :

200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227 Brass body in accordance with EN 1982, EN 12164, EN 12156
