COMBINATION SOAP- AND PAPER TOWEL DISPENSER WP 506
448 x 148 x 164 mm ca. 250 paper towels / 1000 ml soap tank
Combination consisting of a liquid soap dispenser and a paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
Liquid soap dispenser with one-hand operated and non-drip soap pump with 1000 ml tank and pressure valve in brass.
Tank with large, lockable refill opening.
Designed for standard liquid soaps. Accessible for refilling through lockable, removable front panel with fall protection.
Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
Designed for approx. 250 standard paper towels in zigzag- or c-fold. Paper size (folded): 240-250 mm x 100-115 mm. Accessible for refilling through lockable front flap.
Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
Wear parts and front panels can be replaced as modules.
Installation dimensions: 450 x 150 x 154 mm
Mounting: With four screws in wall opening through fixing holes in the side walls.
Delivery includes fixing material and one pack of paper towels.
Weight (in kg): 4,3
AVAILABLE SURFACES
ORDER NUMBERS
satin finished (standard)
727613
highly polished
731613
(coloured) plastic powder - coating
728613
Suggested text for specifications:
Combination consisting of a liquid soap dispenser and a paper towel dispenser in stainless steel (AISI 304) for flush mounting. All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Liquid soap dispenser with one-hand operated and non-drip soap pump with 1000 ml tank and pressure valve in brass. Designed for standard liquid soaps. Accessible for refilling through lockable, removable front panel with fall protection. Paper towel dispenser with deep-drawn paper removal opening, filling quantity approx. 250 paper towels. Accessible for refilling through lockable front flap. Keyed alike cylinder locks in corrosion-resistant zinc die-casting. Delivery includes fixing material and one pack of paper towels.
Full flow straightener Water flow depending on the chosen tapware
> Functionality :
Wall-mounted chrome-plated brass spout without water retention
> Hydraulic supply :
M G 1/2" (15x21) with threaded spigot for cross-partition installation from 200 to 300mm
> Thermal resistance :
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Delivered with :
1 suitable gasket 1 rose 1 flow straightener 1 nut
> Standards & approvals :
Brass body and component in accordance with EN 1982/CC754S, NF EN 12164/CW614N, NF EN 12165/CW617N Molded chrome-plated body in accordance with EN 12540 200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
