UUDIS! PRESTO SAFE® puutetundlik sensoriga kraanid
Lihtne hooldada. Täielik juurdepääs integreeritud süsteemile (aku, solenoidklapp, lahter jne) ilma kraani eemaldamata, avades kaane kraani esiküljel asuva nähtamatu kruviga.
Easy maintenance. Full access to the integrated system (battery, solenoid valve, cell, etc.) without removing the tap by opening the cover with an invisible screw located on the front of the tap.
PRESTO SAFE
Viide: 68077 - Sensoriga kontaktivaba segisti PRESTO SAFE - 3l / min
Töörõhk: 1 kuni 5 baari Voog: 3 l / min integreeritud vooluregulaatoriga Kvaliteetne katlakivivastane aeraator Veevarraste vastane disain Voolu aeg: 7 sekundit reguleeritav PRESTOCOMiga: http://www.presto.fr/whatabout/prestocom/ Eakate ja puuetega inimeste jaoks mõeldud elektrooniline päästikuteta päästik Hüdrauliline toiteallikas: G 3/8 "(12x17) Toide: Integreeritud 9V liitiumaku Materjali ja värvi viimistlus: Messingist kroomitud viimistlus Termiline takistus: Vastupidav temperatuurile 75 ° C 30-minutiliste termiliste löökide korral
PRESTO SAFE
Ref: 68077 - Deck-mounted mixer sensor tap - 3l/min
> Working pressure :
1 to 5 bar
> Flow :
3 l/min with integrated flow regulator High quality anti-limescale aerator Anti-water-hammering design
> Flow time:
7 sec adjustable with PRESTOCOM : http://www.presto.fr/whatabout/prestocom/ Electronic effortless trigger suitable for elderly and disabled people
> Hydraulic supply :
G 3/8" (12x17)
> Power supply :
Integrated 9V lithium battery
> Material and colour finish :
Brass body Chrome finishing
> Thermal resistance :
Resistant to a temperature of 75°C for 30 minute thermal shocks
> Security :
One position temperature limiting system to avoid any risk of scalding Automatic shutdown of solenoid valve in case of power failure or sensor error Duty flush 30 sec each 24h after last use (adjustable flow time and frequency) Low battery alert (blinking led light)
> Delivered with :
1 Brass clamping nut
1 Gasket and 1 Washer
2 PEX Hoses with revolving nuts and NF check valves 2 MM G 3/8" (12x17) Stop valves
2 Filter gaskets
1 Self-adhesive sticker
Instruction manual
> Standards & approvals :
Molded chrome-plated body in accordance with EN 12540
Brass in accordance with NF EN1982, EN12164, EN12165, UBA list compliant 200-hour neutral salt spray resistant (NSS) in accordance with NF ISO 9227 ACS
> Working pressure :
1 to 5 bar
> Flow :
3 l/min with integrated flow regulator High quality anti-limescale aerator Anti-water-hammering design
> Flow time:
7 sec adjustable with PRESTOCOM : http://www.presto.fr/whatabout/prestocom/ Sensor trigger suitable for elderly and disabled people
> Hydraulic supply :
G 1/2" (15x21) - Cold or premixed water
> Power supply :
Integrated 9V lithium battery
> Material and colour finish :
Brass body Chrome finishing
> Thermal resistance :
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Security :
Automatic shutdown of solenoid valve in case of power failure or sensor error Duty flush 30 sec each 24h after last use (adjustable flow time and frequency) Low battery alert (blinking led light)
> Delivered with :
1 Brass clamping nut
1 Gasket and 1 Washer 1 Filter gasket
1 Self-adhesive sticker Instruction manual
> Standards & approvals :
Brass body in accordance with NF EN1982, EN12164, NF EN 12165, UBA list compliant 200-hour neutral salt spray resistant (NSS) in accordance with NF ISO 9227
ACS
> Working pressure :
2 to 5 bar
> Flow :
1.9 l/min with integrated spray flow regulator High quality anti-limescale aerator Anti-water-hammering design
> Flow time:
7 sec adjustable with PRESTOCOM : http://www.presto.fr/whatabout/prestocom/ Sensor trigger suitable for elderly and disabled people
> Hydraulic supply :
G 1/2" (15x21) - Cold or premixed water
> Power supply :
Integrated 9V lithium battery
> Material and colour finish :
Brass body Chrome finishing
> Thermal resistance :
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Security :
Automatic shutdown of solenoid valve in case of power failure or sensor error Duty flush 30 sec each 24h after last use (adjustable flow time and frequency) Low battery alert (blinking led light)
> Delivered with :
1 Brass clamping nut
1 Gasket and 1 Washer 1 Filter gasket
1 Self-adhesive sticker Instruction manual
> Standards & approvals :
Brass body in accordance with NF EN1982, EN12164, NF EN 12165, UBA list compliant 200-hour neutral salt spray resistant (NSS) in accordance with NF ISO 9227
ACS
PRESTO SAFE
Ref: 64681 - Single deck-mounted sensor tap - 1,9l/min
> Working pressure :
2 to 5 bar
> Flow :
1.9 l/min with integrated spray flow regulator High quality anti-limescale aerator Anti-water-hammering design
> Flow time:
7 sec adjustable with PRESTOCOM : http://www.presto.fr/whatabout/prestocom/ Sensor trigger suitable for elderly and disabled people
> Hydraulic supply :
G 1/2" (15x21) - Cold or premixed water
> Power supply :
Integrated 9Vlithium battery
> Material and colour finish :
Brass body Chrome finishing
> Thermal resistance :
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Security :
Automatic shutdown of solenoid valve in case of power failure or sensor error Duty flush 30 sec each 24h after last use (adjustable flow time and frequency) Low battery alert (blinking led light)
> Delivered with :
1 Brass clamping nut
1 Gasket and 1 Washer 1 Filter gasket
1 Self-adhesive sticker Instruction manual
> Standards & approvals :
Brass body in accordance with NF EN1982, EN12164, NF EN 12165, UBA list compliant 200-hour neutral salt spray resistant (NSS) in accordance with NF ISO 9227
ACS
Sensoriga kraan valamule kontaktivaba PRESTO Linea 64679 3l/min 230V
Range: PRESTO LINEA®
Ref: 57200 - Deck-mounted sensor single tap for washbasin, mains 230V, 3l/min with stop valve
> Working pressure:
1 to 5 bar
> Function:
Starts and stops automatically by hand detection
Sensor trigger suitable for PRM, elderly, children and disabled people
> Flow:
3l/min at 3 bar with integrated regulated anti-limescale aerator
> Hydraulic supply:
F G 3/8" (12x17) hose
> Power supply:
Mains-operated with 230 V AC / 7 V DC transformer in IP65 waterproof case
> Material and colour finish:
Chrome-plated brass body with smooth inside body Chrome-plated molded metal cover
> Thermal resistance:
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Security:
Anti-overflow security time set to 30 seconds preventing the water to flow continuously Automatic shutdown of solenoid valve in case of power failure or sensor damage
Duty flush 30 sec every 24h after last use (adjustable flow time and frequency)
Low battery alert (blinking led light)
> Installation:
Recommended installation : 30 cm minimum between the sensor and the basin
> Delivered with:
1 Brass clamping nut, 1 Gasket and 1 WasheTr
1 PEX hose with revolving nut and filter gasket
1 M M G 3/8" (12x17) stop valve
1 Self-adhesive sticker
1 Instruction manual
> Standards & approvals:
Brass body in accordance with NF EN1982, EN12164, NF EN 12165,
UBA list compliant
200-hour neutral salt spray resistant (NSS) in accordance with NF ISO 9227
PRESTO SAFE
Ref: 64679 - Single deck-mounted sensor tap - 3l/min
> Working pressure :
1 to 5 bar
> Flow :
3 l/min with integrated flow regulator High quality anti-limescale aerator Anti-water-hammering design
> Flow time:
7 sec adjustable with PRESTOCOM : http://www.presto.fr/whatabout/prestocom/ Sensor trigger suitable for elderly and disabled people
> Hydraulic supply :
G 1/2" (15x21) - Cold or premixed water
> Power supply :
Integrated 9V lithium battery
> Material and colour finish :
Brass body Chrome finishing
> Thermal resistance :
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Security :
Automatic shutdown of solenoid valve in case of power failure or sensor error Duty flush 30 sec each 24h after last use (adjustable flow time and frequency) Low battery alert (blinking led light)
> Delivered with :
1 Brass clamping nut
1 Gasket and 1 Washer 1 Filter gasket
1 Self-adhesive sticker Instruction manual
> Standards & approvals :
Brass body in accordance with NF EN1982, EN12164, NF EN 12165, UBA list compliant 200-hour neutral salt spray resistant (NSS) in accordance with NF ISO 9227
ACS
> Working pressure :
1 to 5 bar
> Flow :
3 l/min with integrated flow regulator High quality anti-limescale aerator Anti-water-hammering design
> Flow time:
7 sec adjustable with PRESTOCOM : http://www.presto.fr/whatabout/prestocom/ Sensor trigger suitable for elderly and disabled people
> Hydraulic supply :
G 3/8" (12x17)
> Power supply :
Integrated 9V lithium battery
> Material and colour finish :
Brass body Chrome finishing
> Thermal resistance :
Resistant to a temperature of 75°C for 30 minute thermal shocks
> Security :
One position temperature limiting system to avoid any risk of scalding Automatic shutdown of solenoid valve in case of power failure or sensor error Duty flush 30 sec each 24h after last use (adjustable flow time and frequency) Low battery alert (blinking led light)
> Delivered with :
1 Brass clamping nut
1 Gasket and 1 Washer
2 PEX Hoses with revolving nuts and NF check valves 2 MM G 3/8" (12x17) Stop valves
2 Filter gaskets
1 Self-adhesive sticker
Instruction manual
> Standards & approvals :
Molded chrome-plated body in accordance with EN 12540
Brass in accordance with NF EN1982, EN12164, EN12165, UBA list compliant 200-hour neutral salt spray resistant (NSS) in accordance with NF ISO 9227 ACS
