COMBINATION PAPER TOWEL DISPENSER AND WASTE BIN WP 530
298 x 898 x 120 mm ca. 250 paper towels / 11 l
Combination consisting of a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
Designed for approx. 250 standard paper towels in zigzag fold. Paper size (folded): 240-250 mm x 100-115 mm.
Inspection slot to indicate fill level.
Accessible for refilling through lockable front flap with fall protection.
Waste bin equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
Wear parts and front panels can be replaced as modules.
Installation dimensions: 300 x 900 x 110 mm
Mounting: With four screws in wall opening through fixing holes in the side walls.
Delivery includes fixing material and one pack of paper towels.
Weight (in kg): 9,3
AVAILABLE SURFACES
ORDER NUMBERS
satin finished (standard)
722982
highly polished
731982
(coloured) plastic powder - coating
728092
Suggested text for specifications:
Combination consisting of a paper towel dispenser and a waste bin in stainless steel (AISI 304) for flush mounting. All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Paper towel dispenser with deep-drawn paper removal opening, filling quantity approx. 250 paper towels. Inspection slot to indicate fill level. Accessible for refilling through lockable front flap with fall protection. Waste bin equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap. Keyed alike cylinder locks in corrosion-resistant zinc die-casting. Delivery includes fixing material and one pack of paper towels.
Separett Privy on uriinieraldajaga komplekt kuivkäimla tarvis ning on lihtsalt paigaldatav olemasolevasse puidust istelauaga kuivkäimlasse.
Uriin ja tahke komponent hoitakse lahus. Tulemuseks on haisuvaba käimla, kuivolluse math mäheneb oluliselt ning seda on hõlpsam käsitleda.
Uriin suunatakse painduva vooliku abil kas kanalisatsiooni või kogumisnõusse. Tahke olluse tarvis võib kasutada lisatarvikute hulgas pakutavaid kogumisnõusid ja jäätmekotte.
Komplekt sisaldab kuivkäimla iste koos kaanega, mis on teeb käimla kasutamise mugavaks aastaringselt.
Privy 500 komplekti kuuluvad:
Uriinieraldaja, iste kaanega, painduv uriinivoolik pikkusega 2,5m.
